Use this SKF deep-groove ball bearing to handle high-speed operations. It bears radial and axial loads, so it's a versatile option. It has an inside diameter of 180 mm, an outside diameter of 250 mm and a 33 mm race width. As an open-type ball bearing, it's easy to re-lubricate and allows the lubricant to travel freely around the bearing. Open-end bearings like this are best-suited to clean environments where dirt is unlikely to enter them.

• Generates low friction torque, which lowers the operating temperature and saves on energy consumption
• Significantly reduced structural resonance for a quieter operation
• Made of bearing steel for hardness retention and toughness

• Vehicle manufacturing
• Construction equipment
• Manufacturing

Deep-groove ball bearings have an inner ring and an outer ring with balls sitting in a deep raceway in between. They can work at high speeds and handle loads in both directions.

Low-viscosity oils are the best lubricants for open bearing designs. They enable the bearing to run efficiently and reach higher speeds with lower friction.
