SKF 61936 MA Single Row Deep Groove Ball Bearing- Open Type 180mm I.D, 250mm O.D
- RS Stock No.:
- 207-7067
- Mfr. Part No.:
- 61936 MA
- Brand:
- SKF
Subtotal (1 unit)*
£1,412.73
(exc. VAT)
£1,695.28
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 999,999,999 unit(s) shipping from 03 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £1,412.73 |
*price indicative
- RS Stock No.:
- 207-7067
- Mfr. Part No.:
- 61936 MA
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | SKF | |
Inside Diameter | 180mm | |
Outside Diameter | 250mm | |
Race Width | 33mm | |
Ball Bearing Type | Single Row Deep Groove Ball Bearing | |
Sealing Arrangement | Open Type | |
Bearing Clearance | CN | |
Material | Steel | |
Ball Material | Steel | |
Cage Material | Machined Metal | |
Number of Rows | 1 | |
Static Load Rating | 134kN | |
Dynamic Load Rating | 119kN | |
Bore Type | Parallel | |
Bearing Series | 1 Extra Light Thrust | |
Partial Bearing Code | 61936 | |
Select all | ||
---|---|---|
Brand SKF | ||
Inside Diameter 180mm | ||
Outside Diameter 250mm | ||
Race Width 33mm | ||
Ball Bearing Type Single Row Deep Groove Ball Bearing | ||
Sealing Arrangement Open Type | ||
Bearing Clearance CN | ||
Material Steel | ||
Ball Material Steel | ||
Cage Material Machined Metal | ||
Number of Rows 1 | ||
Static Load Rating 134kN | ||
Dynamic Load Rating 119kN | ||
Bore Type Parallel | ||
Bearing Series 1 Extra Light Thrust | ||
Partial Bearing Code 61936 | ||
- COO (Country of Origin):
- FR
SKF Deep-Groove Ball Bearing, 180 mm ID, 250 mm OD - 61936 MA
Use this SKF deep-groove ball bearing to handle high-speed operations. It bears radial and axial loads, so it's a versatile option. It has an inside diameter of 180 mm, an outside diameter of 250 mm and a 33 mm race width. As an open-type ball bearing, it's easy to re-lubricate and allows the lubricant to travel freely around the bearing. Open-end bearings like this are best-suited to clean environments where dirt is unlikely to enter them.
• Generates low friction torque, which lowers the operating temperature and saves on energy consumption
• Significantly reduced structural resonance for a quieter operation
• Made of bearing steel for hardness retention and toughness
• Significantly reduced structural resonance for a quieter operation
• Made of bearing steel for hardness retention and toughness
Application Information
• Vehicle manufacturing
• Construction equipment
• Manufacturing
• Construction equipment
• Manufacturing
Why use a deep-groove ball bearing?
Deep-groove ball bearings have an inner ring and an outer ring with balls sitting in a deep raceway in between. They can work at high speeds and handle loads in both directions.
What lubricant should I use for an open-type ball bearing?
Low-viscosity oils are the best lubricants for open bearing designs. They enable the bearing to run efficiently and reach higher speeds with lower friction.
