SKF 6040 M/C3 Single Row Deep Groove Ball Bearing- Open Type 200mm I.D, 310mm O.D
- RS Stock No.:
- 207-6946
- Mfr. Part No.:
- 6040 M/C3
- Brand:
- SKF
Subtotal (1 unit)*
£1,462.00
(exc. VAT)
£1,754.40
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 04 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,462.00 |
*price indicative
- RS Stock No.:
- 207-6946
- Mfr. Part No.:
- 6040 M/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 200mm | |
| Outside Diameter | 310mm | |
| Race Width | 51mm | |
| Ball Bearing Type | Single Row Deep Groove Ball Bearing | |
| Sealing Arrangement | Open Type | |
| Bearing Clearance | C3 | |
| Material | Steel | |
| Ball Material | Steel | |
| Cage Material | Machined Metal | |
| Number of Rows | 1 | |
| Static Load Rating | 245kN | |
| Dynamic Load Rating | 216kN | |
| Bore Type | Parallel | |
| Bearing Series | 0 Extra Light | |
| Partial Bearing Code | 6040 | |
| Model Number p | 6040 M/C3 | |
Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 200mm | ||
Outside Diameter 310mm | ||
Race Width 51mm | ||
Ball Bearing Type Single Row Deep Groove Ball Bearing | ||
Sealing Arrangement Open Type | ||
Bearing Clearance C3 | ||
Material Steel | ||
Ball Material Steel | ||
Cage Material Machined Metal | ||
Number of Rows 1 | ||
Static Load Rating 245kN | ||
Dynamic Load Rating 216kN | ||
Bore Type Parallel | ||
Bearing Series 0 Extra Light | ||
Partial Bearing Code 6040 | ||
Model Number p 6040 M/C3 | ||
- COO (Country of Origin):
- FR
SKF Deep-Groove Ball Bearing, 200 mm ID, 310 mm OD - 6040 M/C3
Looking for a ball bearing to rotate components at high speeds? This versatile deep-groove choice from SKF can support both radial and axial loads in both directions, making it suitable for a wide range of applications. It has an inside diameter of 200 mm and an outside diameter of 310 mm, with a race width of 51 mm. As an open-type ball bearing, it's easy to re-lubricate and allows the lubricant to circulate freely in the bearing. Bearings of this type are suitable for use in clean environments where dirt won't contaminate them.
• Rotates with less friction torque for low-temperature operation
• Durable steel material
• Simple design needs minimal maintenance
• Durable steel material
• Simple design needs minimal maintenance
Application Information
• Power industries
• Machine tools
• Vehicle manufacture
• Machine tools
• Vehicle manufacture
Why are deep-groove ball bearings a good choice?
Deep-groove ball bearings are optimised for quiet operation, so they enhance your working environment.
What maintenance does an open-type ball bearing need?
Lubricating your open bearings with low-viscosity oil (rather than grease) will keep them operating with minimal friction and at reliably high speeds.
