NSK 626ZZ 1 Row Deep Groove Ball Bearing - 6 mm ID, 19 mm OD
- RS Stock No.:
- 644-007
- Mfr. Part No.:
- 626ZZ
- Brand:
- NSK
Subtotal (1 unit)*
£3.03
(exc. VAT)
£3.64
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 66 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £3.03 |
*price indicative
- RS Stock No.:
- 644-007
- Mfr. Part No.:
- 626ZZ
- Brand:
- NSK
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | NSK | |
| Inside Diameter | 6 mm | |
| Product Type | Deep Groove Ball Bearing | |
| Outside Diameter | 19 mm | |
| Race Width | 6mm | |
| Cage Material | Steel | |
| Ball Material | Steel | |
| Number of Rows | 1 | |
| Static Load Rating | 885N | |
| Dynamic Load Rating | 2570N | |
| Bore Type | Parallel | |
| Standards/Approvals | No | |
| Limiting Speed | 32000rpm | |
| Bearing Type | Single Row Deep Groove Ball | |
| Race Type | Plain | |
| Select all | ||
|---|---|---|
Brand NSK | ||
Inside Diameter 6 mm | ||
Product Type Deep Groove Ball Bearing | ||
Outside Diameter 19 mm | ||
Race Width 6mm | ||
Cage Material Steel | ||
Ball Material Steel | ||
Number of Rows 1 | ||
Static Load Rating 885N | ||
Dynamic Load Rating 2570N | ||
Bore Type Parallel | ||
Standards/Approvals No | ||
Limiting Speed 32000rpm | ||
Bearing Type Single Row Deep Groove Ball | ||
Race Type Plain | ||
Non Compliant
- COO (Country of Origin):
- ID
The NSK Extra small ball bearing designed for high-speed applications. It features a 6 mm bore diameter, 19 mm outer diameter, and 6 mm width, making it ideal for miniature mechanical systems. The bearing is equipped with double metal shields (ZZ) to provide effective protection against contaminants while maintaining low friction and smooth operation.
Robust and compact construction for space efficient installation
High quality bearing steel ensures excellent durability
Lightweight design
