SKF 6213-2RS1/C3 1 Row Ball Bearing - 65 mm ID, 120 mm OD
- RS Stock No.:
- 506-012
- Mfr. Part No.:
- 6213-2RS1/C3
- Brand:
- SKF
Bulk discount available
Subtotal (1 unit)*
£55.63
(exc. VAT)
£66.76
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 4 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £55.63 |
| 5 - 9 | £54.08 |
| 10 - 24 | £52.63 |
| 25 + | £51.25 |
*price indicative
- RS Stock No.:
- 506-012
- Mfr. Part No.:
- 6213-2RS1/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 65mm | |
| Product Type | Ball Bearing | |
| Outside Diameter | 120mm | |
| Race Width | 23mm | |
| Ball Material | Steel | |
| Cage Material | Sheet Metal | |
| End Type | Sealed | |
| Number of Rows | 1 | |
| Static Load Rating | 40.5kN | |
| Internal Clearance | C3 | |
| Dynamic Load Rating | 58.5kN | |
| Series | 2 Light | |
| Bore Type | Parallel | |
| Standards/Approvals | No | |
| Limiting Speed | 3600rpm | |
| Bearing Type | Single Row Deep Groove Ball | |
| Race Type | Plain | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 65mm | ||
Product Type Ball Bearing | ||
Outside Diameter 120mm | ||
Race Width 23mm | ||
Ball Material Steel | ||
Cage Material Sheet Metal | ||
End Type Sealed | ||
Number of Rows 1 | ||
Static Load Rating 40.5kN | ||
Internal Clearance C3 | ||
Dynamic Load Rating 58.5kN | ||
Series 2 Light | ||
Bore Type Parallel | ||
Standards/Approvals No | ||
Limiting Speed 3600rpm | ||
Bearing Type Single Row Deep Groove Ball | ||
Race Type Plain | ||
RoHS Status: Exempt
- COO (Country of Origin):
- FR
SKF Ball Bearing, 65mm Inside Diameter, 120mm Outside Diameter - 6213-2RS1/C3
This ball bearing is a single row deep groove type, specifically designed for high performance and durability. With an inner diameter of 65mm and an outer diameter of 120mm, it is well-suited for various applications in the automation, mechanical, and electrical industries. This sealed ball bearing features a robust steel construction, ensuring long-lasting functionality under load.
Features & Benefits
• Sealed design provides enhanced protection against contaminants
• C3 clearance bearing allows for more operational flexibility
• High static load rating of 40.5 kN ensures reliability
• Exceptional dynamic load rating of 58.5 kN supports heavy tasks
• Supports speeds up to 3600r/min for efficient performance
• Plain race ball bearing design reduces friction during operation
• C3 clearance bearing allows for more operational flexibility
• High static load rating of 40.5 kN ensures reliability
• Exceptional dynamic load rating of 58.5 kN supports heavy tasks
• Supports speeds up to 3600r/min for efficient performance
• Plain race ball bearing design reduces friction during operation
Applications
• Used with electric motors to ensure smooth rotation
• Utilised in gearboxes for effective power transmission
• Ideal for conveyors to facilitate consistent movement
• Applied in HVAC systems for optimal fan and pump operations
• Utilised in gearboxes for effective power transmission
• Ideal for conveyors to facilitate consistent movement
• Applied in HVAC systems for optimal fan and pump operations
What is the suitable operating speed range for this product?
It can operate efficiently up to 3600r/min, making it suitable for high-speed applications where reliability is essential.
How does the sealing arrangement contribute to its performance?
The sealed design on both sides prevents dust and moisture ingress, thus maintaining performance and extending service life even in challenging environments.
What load capabilities should I consider for my application?
With a dynamic load rating of 58.5 kN and static load rating of 40.5 kN, this product is Ideal for applications involving substantial weight and mechanical stress.
What materials are used in the construction of this bearing?
Constructed from high-quality steel, both the balls and outer materials provide strength and durability, ensuring long-term use in rigorous conditions.
How does the C3 clearance impact its use in machinery?
The C3 clearance facilitates a better fit and operation in environments where slight variations in temperature may occur, promoting efficient performance under varying conditions.
