SKF 6304-2ZNR 1 Row Deep Groove Ball Bearing - 20 mm ID, 52 mm OD
- RS Stock No.:
- 461-361
- Mfr. Part No.:
- 6304-2ZNR
- Brand:
- SKF
Subtotal (1 unit)*
£27.85
(exc. VAT)
£33.42
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 25 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £27.85 |
*price indicative
- RS Stock No.:
- 461-361
- Mfr. Part No.:
- 6304-2ZNR
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 20 mm | |
| Product Type | Deep Groove Ball Bearing | |
| Outside Diameter | 52 mm | |
| Race Width | 15mm | |
| Ball Material | Bearing Steel | |
| Cage Material | Sheet Metal | |
| Race Material | Bearing Steel | |
| End Type | Shielded | |
| Number of Rows | 1 | |
| Internal Clearance | CN | |
| Static Load Rating | 7.8kN | |
| Dynamic Load Rating | 16.8kN | |
| Series | 6304-2ZNR | |
| Bore Type | Cylindrical | |
| Standards/Approvals | No | |
| Limiting Speed | 15000rpm | |
| Bearing Type | Deep Groove Ball | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 20 mm | ||
Product Type Deep Groove Ball Bearing | ||
Outside Diameter 52 mm | ||
Race Width 15mm | ||
Ball Material Bearing Steel | ||
Cage Material Sheet Metal | ||
Race Material Bearing Steel | ||
End Type Shielded | ||
Number of Rows 1 | ||
Internal Clearance CN | ||
Static Load Rating 7.8kN | ||
Dynamic Load Rating 16.8kN | ||
Series 6304-2ZNR | ||
Bore Type Cylindrical | ||
Standards/Approvals No | ||
Limiting Speed 15000rpm | ||
Bearing Type Deep Groove Ball | ||
- COO (Country of Origin):
- BG
Gavin
The SKF Single row deep groove ball bearings with seals or shields are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types. The integral sealing can significantly prolong bearing service life because it keeps lubricant in the bearings and contaminants out.
Low friction
High speed capability
Accommodate radial and axial loads in both directions
