Sifam Tinsley DE Analogue Panel Ammeter 100 A AC, 0.5 % Moving Iron
- RS Stock No.:
- 886-1881
- Mfr. Part No.:
- EQ74-I1522N1CAW0ST
- Brand:
- Sifam Tinsley
Bulk discount available
Subtotal (1 unit)*
£12.54
(exc. VAT)
£15.05
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 37 unit(s) ready to ship
- Plus 18 unit(s) ready to ship from another location
- Plus 12 unit(s) shipping from 11 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £12.54 |
| 5 - 9 | £12.03 |
| 10 + | £11.66 |
*price indicative
- RS Stock No.:
- 886-1881
- Mfr. Part No.:
- EQ74-I1522N1CAW0ST
- Brand:
- Sifam Tinsley
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Sifam Tinsley | |
| Product Type | Analogue Panel Ammeter | |
| Current Type | AC | |
| Moving Element | Moving Iron | |
| Depth | 54mm | |
| Meter Accuracy | 0.5 % | |
| Maximum Operating Temperature | 55°C | |
| Maximum Ampere Value | 100 A | |
| Minimum Operating Temperature | -10°C | |
| Standards/Approvals | IEC 60051, DIN 43701, DIN 43807, DIN 46200/46282, IS : 1248, DIN 40050, VDE 0410, IS 9249, VDE / VDI 3540, VDE 0110, DIN 43802, IEC51/DINEN60051, IEC 529, DIN IEC 61554, UL 94 V-0, DIN 43718, IEC 1010, CE ing (2004 / 108 / EC,2006 / 95/EC,93/68/EEC)) | |
| Minimum Measurement | 6 V, 100 mA | |
| Maximum Measurement | 1000V, 100 A | |
| Series | DE | |
| Select all | ||
|---|---|---|
Brand Sifam Tinsley | ||
Product Type Analogue Panel Ammeter | ||
Current Type AC | ||
Moving Element Moving Iron | ||
Depth 54mm | ||
Meter Accuracy 0.5 % | ||
Maximum Operating Temperature 55°C | ||
Maximum Ampere Value 100 A | ||
Minimum Operating Temperature -10°C | ||
Standards/Approvals IEC 60051, DIN 43701, DIN 43807, DIN 46200/46282, IS : 1248, DIN 40050, VDE 0410, IS 9249, VDE / VDI 3540, VDE 0110, DIN 43802, IEC51/DINEN60051, IEC 529, DIN IEC 61554, UL 94 V-0, DIN 43718, IEC 1010, CE ing (2004 / 108 / EC,2006 / 95/EC,93/68/EEC)) | ||
Minimum Measurement 6 V, 100 mA | ||
Maximum Measurement 1000V, 100 A | ||
Series DE | ||
Non Compliant
Sigma Series DE Panel Meter
These Sigma Series of DE moving iron panel meters are housed in moulded polycarbonate cases and are suitable for the measurement of AC currents for a frequency range of 15-400Hz and voltages in the frequency range of 15-100Hz.
Available in variety of sizes for both Ammeters & Voltmeters
Scale interchangeability
Near linear scale
Glass filled polycarbonate housing
Knife edge pointer
Easily replace able glass and bezel
Sifam Tinsley Moving Iron Panel Meters
