Nichicon 220μF Aluminium Electrolytic Capacitor 350V dc, Radial, Through Hole - UCY2V221MHD
- RS Stock No.:
- 243-7279
- Mfr. Part No.:
- UCY2V221MHD
- Brand:
- Nichicon
Bulk discount available
Subtotal (1 tape of 5 units)*
£19.36
(exc. VAT)
£23.23
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 165 unit(s) shipping from 06 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
---|---|---|
5 - 45 | £3.872 | £19.36 |
50 - 245 | £2.936 | £14.68 |
250 + | £2.266 | £11.33 |
*price indicative
- RS Stock No.:
- 243-7279
- Mfr. Part No.:
- UCY2V221MHD
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Nichicon | |
Capacitance | 220µF | |
Voltage | 350V dc | |
Mounting Type | Radial, Through Hole | |
Technology | Aluminium Electrolytic | |
Dimensions | 18 (Dia.) x 46mm | |
Diameter | 18mm | |
Maximum Operating Temperature | +105°C | |
Series | UCY | |
Automotive Standard | AEC-Q200 | |
Select all | ||
---|---|---|
Brand Nichicon | ||
Capacitance 220µF | ||
Voltage 350V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 18 (Dia.) x 46mm | ||
Diameter 18mm | ||
Maximum Operating Temperature +105°C | ||
Series UCY | ||
Automotive Standard AEC-Q200 | ||
- COO (Country of Origin):
- JP
The Nichicon's UCY series is miniature size aluminium capacitor have high ripple current and high reliability.
High ripple current and Long Life product withstanding load life of 10000 to 12000 hours at +105°C
Suited for power supply and ballast application
Compliant to the RoHS directive (2011/65/EU,(EU) 2015/863)
AEC-Q200 compliant
Suited for power supply and ballast application
Compliant to the RoHS directive (2011/65/EU,(EU) 2015/863)
AEC-Q200 compliant
