Capacitors

Capacitors are passive electrical components found in almost all electronics applications. Our range includes over 60,000 different capacitors including aluminium, tantalum, polymer, polyester film and ceramic capacitors. We source from globally renowned manufacturers AVX, Murata, KEMET, Panasonic, TDK and many more, so that you can rely on performance.

What is a capacitor and what does it do?

A capacitor is a device used to store energy as an electric charge, similar to a battery but they are able to release the charge much faster. The amount it's able to store is known as capacitance, this is measured in Farads (F). They comprise 2 metal plates (conductors) separated by an electrical insulator (dielectric).

What capacitor types are available?

There are many different types available with detailed specifications for their required function. The main elements are available in varying materials and these determine many properties of the capacitor. Some factors to consider are:

  • Metal plate material - e.g silver, tantalum, aluminium
  • Dielectric plate material - paper, film, ceramic, glass
  • Max voltage - cannot be exceeded or the device will break
  • Size - capacitance and dimensions
  • Tolerance - variance on the capacitance value
  • Mounting type - how it is fixed to the circuit
  • ESR (Equivalent series resistance) - resistance of the terminals

Applications of capacitors

Capacitors are found all around us, they are used in most electronics from fans to hybrid electric cars - there are over 500 just in a typical smartphone. Here are some of their uses:

  • Decoupling capacitors - can control high-frequency noise, removing voltage ripples from the power supply.
  • Energy storage and supply - deliver stored energy bursts quickly, like a camera flash for example.
  • Signal filtering - they are able to block low-frequency signals and allow higher-frequencies to pass through. Useful in telecommunications.
Calibrate new and existing equipment
Get a quote online, quick and easy
Return online within 30 days

Guides & Articles

article1_image

In our comprehensive Capacitors Guide we look at MLCC's and the alternatives available

article1_image

Everything you need to know about variable resistors

Related Products
Cooper Bussman TV Series cells provide ultra-high capacitance ...
Description:
Cooper Bussman TV Series cells provide ultra-high capacitance energy storage for high-power charge/discharge cycling, peak power shaving and back up power applications. They also provide power to safely shut down systems and avoid data loss when main power is disconnected. 3.0 V operating voltage for high power and High energyUltra ...
KEMET FM series super capacitors are designed for ...
Description:
KEMET FM series super capacitors are designed for high energy storage applications.supercapacitors can be used like a secondary battery when applied in a DC circuit. These supercapacitors are suited for use in low voltage DC hold-up applications such asembedded microprocessor systems with flash memory. Rectangular caseWide range of temperature from ...
KEMET FC Supercapacitors are surface mount capacitors for ...
Description:
KEMET FC Supercapacitors are surface mount capacitors for use with high energy applications. These supercapacitors are designed especially for reflow soldering, allowing them to be attached to the printed circuit board directly. Wide range of temperature from −25°C to +70°CSurface mount without holderOperational Voltage: 3.5 to 5.5 V dcHighly reliable ...
The Eaton XLM provides energy storage for bridge ...
Description:
The Eaton XLM provides energy storage for bridge power uninterruptible power supplies (UPS) and improves power quality for voltage spikes and brown outs. The XLM is a safer alternative to batteries for UPS back up power applications. Supercapacitor modules require no battery management system (BMS) due to Eaton’s patented active ...
