Nichicon 4.7 μF Capacitor 350V dc, Radial, Through Hole Radial Lead
- RS Stock No.:
- 762-1890
- Mfr. Part No.:
- UBT2V4R7MPD8
- Brand:
- Nichicon
Subtotal (1 pack of 5 units)*
£4.06
(exc. VAT)
£4.87
(inc. VAT)
FREE delivery for orders over £60.00
Being discontinued
- Plus 120 unit(s) shipping from 20 July 2026
- Final 840 unit(s) shipping from 27 July 2026
Units | Per unit | Per Pack* |
|---|---|---|
| 5 + | £0.812 | £4.06 |
*price indicative
- RS Stock No.:
- 762-1890
- Mfr. Part No.:
- UBT2V4R7MPD8
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Product Type | Capacitor | |
| Capacitance | 4.7μF | |
| Voltage | 350V dc | |
| Mount Type | Radial, Through Hole | |
| Construction | Radial Can | |
| Polarity | Polar | |
| Height | 20mm | |
| Length | 11.5mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 10mm | |
| Termination Type | Radial Lead | |
| Pin Count | 2 | |
| Capacitor Ripple Current | 53mA | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | RoHS | |
| Lead Pitch | 5mm | |
| Lifetime | 2000 h | |
| Tolerance | ±20 % | |
| Series | BT | |
| Automotive Standard | No | |
| Dissipation Factor | 24% | |
| Select all | ||
|---|---|---|
Brand Nichicon | ||
Product Type Capacitor | ||
Capacitance 4.7μF | ||
Voltage 350V dc | ||
Mount Type Radial, Through Hole | ||
Construction Radial Can | ||
Polarity Polar | ||
Height 20mm | ||
Length 11.5mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 10mm | ||
Termination Type Radial Lead | ||
Pin Count 2 | ||
Capacitor Ripple Current 53mA | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals RoHS | ||
Lead Pitch 5mm | ||
Lifetime 2000 h | ||
Tolerance ±20 % | ||
Series BT | ||
Automotive Standard No | ||
Dissipation Factor 24% | ||
- COO (Country of Origin):
- JP
BT Series High Temperature (PET Sleeve)
Nichicon BT Series Aluminium Electrolytic Capacitors are high reliability, low impedance and a miniature size that offer a 10000-hour load life. The BT series features a high temperature range, a wide rated voltage range, and high ripple current. Suitable for automobile electronics where heavy-duty services are indispensable.
Features & Benefits:
High reliability
High ripple current
Long life up to 10,000 hours
