Nichicon 220μF Aluminium Electrolytic Capacitor 350V dc, Radial, Through Hole - UCY2V221MHD
- RS Stock No.:
- 243-7278
- Mfr. Part No.:
- UCY2V221MHD
- Brand:
- Nichicon
50 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 50)
£3.33
(exc. VAT)
£4.00
(inc. VAT)
| Units | Per unit | Per Pack* |
| 50 + | £3.33 | £166.50 |
| *price indicative | ||
- RS Stock No.:
- 243-7278
- Mfr. Part No.:
- UCY2V221MHD
- Brand:
- Nichicon
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
The Nichicon's UCY series is miniature size aluminium capacitor have high ripple current and high reliability.
High ripple current and Long Life product withstanding load life of 10000 to 12000 hours at +105°C
Suited for power supply and ballast application
Compliant to the RoHS directive (2011/65/EU,(EU) 2015/863)
AEC-Q200 compliant
Suited for power supply and ballast application
Compliant to the RoHS directive (2011/65/EU,(EU) 2015/863)
AEC-Q200 compliant
Specifications
Attribute | Value |
|---|---|
| Capacitance | 220µF |
| Voltage | 350V dc |
| Mounting Type | Radial, Through Hole |
| Technology | Aluminium Electrolytic |
| Dimensions | 18 (Dia.) x 46mm |
| Diameter | 18mm |
| Maximum Operating Temperature | +105°C |
| Automotive Standard | AEC-Q200 |
| Series | UCY |
