Deltron Panel XLR Connector, Straight, 50V ac Female, 4 Way, Silver Plating
- RS Stock No.:
- 180-6789
- Mfr. Part No.:
- 716-0400
- Brand:
- Deltron
Subtotal (1 unit)*
£12.80
(exc. VAT)
£15.36
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 66 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £12.80 |
*price indicative
- RS Stock No.:
- 180-6789
- Mfr. Part No.:
- 716-0400
- Brand:
- Deltron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Deltron | |
| Number of Contacts | 4 | |
| Product Type | XLR Connector | |
| Mount Type | Panel | |
| Current | 10A | |
| Orientation | Straight | |
| Connector Gender | Female | |
| Colour | Silver | |
| Contact Plating | Silver | |
| Housing Material | Zinc Alloy | |
| Termination Type | Screw | |
| Minimum Operating Temperature | -25°C | |
| Voltage | 50V ac | |
| Maximum Operating Temperature | 70°C | |
| Contact Gender | Female | |
| Contact Material | Brass | |
| Length | 31.6mm | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand Deltron | ||
Number of Contacts 4 | ||
Product Type XLR Connector | ||
Mount Type Panel | ||
Current 10A | ||
Orientation Straight | ||
Connector Gender Female | ||
Colour Silver | ||
Contact Plating Silver | ||
Housing Material Zinc Alloy | ||
Termination Type Screw | ||
Minimum Operating Temperature -25°C | ||
Voltage 50V ac | ||
Maximum Operating Temperature 70°C | ||
Contact Gender Female | ||
Contact Material Brass | ||
Length 31.6mm | ||
Standards/Approvals No | ||
The 7000 Universal Range of Audio and Video Connectors employs many innovative features unique to the Deltron series. They are suitable for use in both commercial and industrial electronics applications, where reliability, simple operation and the elimination of RF and mechanical interference is necessary. Common uses include mixing desks, tape recorders, video recorders, DAT recorders and test instrumentation.
Completely interchangeable with all leading manufacturers of XLRs
HOUSING: a rugged diecasting offering full RF protection, with a small industrial standard flange
INSERT: thermoplastic with high mechanical, thermal and electrical properties excellent chemical resistance, and dimensional stability
CONTACTS: precision machined in brass with generous solder buckets to accept a wide range of cable sizes
LATCHING: a unique design with minimum press action offering the widest latching area for positive locking ad straight through grounding
