Assemtech 15 ° Horizontal Tilt Switch 1 A 120 V ac
- RS Stock No.:
- 618-7507
- Mfr. Part No.:
- S1016CW
- Brand:
- Assemtech
Subtotal (1 unit)*
£17.94
(exc. VAT)
£21.53
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 199 unit(s) shipping from 20 July 2026
- Plus 48 unit(s) shipping from 20 July 2026
- Plus 151 unit(s) shipping from 12 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £17.94 |
*price indicative
- RS Stock No.:
- 618-7507
- Mfr. Part No.:
- S1016CW
- Brand:
- Assemtech
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Assemtech | |
| Differential Angle | 15 ° | |
| Product Type | Tilt Switch | |
| Mounting Orientation | Horizontal | |
| Maximum Current | 1A | |
| Maximum AC Voltage | 120V ac | |
| Contact Resistance | 3Ω | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 70°C | |
| Diameter | 13mm | |
| Length | 196.5mm | |
| Standards/Approvals | RoHS | |
| Series | S10 | |
| Select all | ||
|---|---|---|
Brand Assemtech | ||
Differential Angle 15 ° | ||
Product Type Tilt Switch | ||
Mounting Orientation Horizontal | ||
Maximum Current 1A | ||
Maximum AC Voltage 120V ac | ||
Contact Resistance 3Ω | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 70°C | ||
Diameter 13mm | ||
Length 196.5mm | ||
Standards/Approvals RoHS | ||
Series S10 | ||
- COO (Country of Origin):
- GB
Tilt Switch with Mounting Clip
This tilt switch operates when tilted from the horizontal position. It is robust and fully sealed to offer maximum protection. It is suitable for numerous applications including switching inductive and capacitance loads, motors and incandescent lamps.
Features and Benefits
• Mercury-free tilt switch
• Differential angle of 15 °
• Fully sealed to give maximum protection
• Ideal for use in numerous applications
• Wide operating temperature -20 °C to +70°C
• Black insulated IP65 plastic housing
• Mounting clip supplied
