Igus 13 Teeth Spur Gear, 0.5 Module, 2 mm Bore Diam, 6.5 mm Pitch Diam, 4 mm Hub Diam
- RS Stock No.:
- 272-5464
- Mfr. Part No.:
- P360GM-ST-050-013-00-020-R
- Brand:
- Igus
Subtotal (1 unit)*
£3.01
(exc. VAT)
£3.61
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £3.01 |
*price indicative
- RS Stock No.:
- 272-5464
- Mfr. Part No.:
- P360GM-ST-050-013-00-020-R
- Brand:
- Igus
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Igus | |
| Product Type | Spur Gear | |
| Module | 0.5 | |
| Number of Teeth | 13 | |
| Bore Size | 2 mm | |
| Pitch Diameter | 6.5mm | |
| Hub Diameter | 4mm | |
| Face Width | 3mm | |
| Pressure Angle | 20° | |
| Standards/Approvals | RoHS | |
| Series | P360GM | |
| Select all | ||
|---|---|---|
Brand Igus | ||
Product Type Spur Gear | ||
Module 0.5 | ||
Number of Teeth 13 | ||
Bore Size 2 mm | ||
Pitch Diameter 6.5mm | ||
Hub Diameter 4mm | ||
Face Width 3mm | ||
Pressure Angle 20° | ||
Standards/Approvals RoHS | ||
Series P360GM | ||
The Igus Spur gear with good tribological specifications provide a positive, constant speed drive to facilitate daily industrial operations. Its maintenance free properties reduce costs for lubrication and maintenance.
Very tough
Resistant to shock loads
