Igus 13 Teeth Spur Gear, 2.5 Module, 10mm Bore, 32.5 mm Pitch Diam, 20 mm Hub Diam
- RS Stock No.:
- 272-5713
- Mfr. Part No.:
- P360GM-ST-250-013-00-100-R
- Brand:
- Igus
Subtotal (1 unit)*
£34.27
(exc. VAT)
£41.12
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 24 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £34.27 |
*price indicative
- RS Stock No.:
- 272-5713
- Mfr. Part No.:
- P360GM-ST-250-013-00-100-R
- Brand:
- Igus
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Igus | |
| Product Type | Spur Gear | |
| Module | 2.5 | |
| Number of Teeth | 13 | |
| Bore Diameter | 10mm | |
| Pitch Diameter | 32.5mm | |
| Hub Diameter | 20mm | |
| Face Width | 17mm | |
| Pressure Angle | 20° | |
| Series | P360GM | |
| Standards/Approvals | RoHS | |
| Select all | ||
|---|---|---|
Brand Igus | ||
Product Type Spur Gear | ||
Module 2.5 | ||
Number of Teeth 13 | ||
Bore Diameter 10mm | ||
Pitch Diameter 32.5mm | ||
Hub Diameter 20mm | ||
Face Width 17mm | ||
Pressure Angle 20° | ||
Series P360GM | ||
Standards/Approvals RoHS | ||
- COO (Country of Origin):
- DE
The Igus Spur gear with good tribological specifications provide a positive, constant speed drive to facilitate daily industrial operations. Its maintenance free properties reduce costs for lubrication and maintenance.
Very tough
Resistant to shock loads
