WAGO, 221 Wire Splice Splice Connector, Clear, Insulated, Tin 12 AWG
- RS Stock No.:
- 303-353
- Mfr. Part No.:
- 2773-2401/995-020
- Brand:
- WAGO
Bulk discount available
Subtotal (1 pack of 20 units)*
£8.48
(exc. VAT)
£10.18
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 15 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 - 4 | £8.48 | £0.424 |
| 5 - 9 | £7.80 | £0.39 |
| 10 + | £6.88 | £0.344 |
*price indicative
- RS Stock No.:
- 303-353
- Mfr. Part No.:
- 2773-2401/995-020
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | Splice Connector | |
| Splice Type | Wire Splice | |
| Overall Length | 29.5mm | |
| Minimum Wire Size AWG | 18 AWG | |
| Diameter | 2 mm | |
| Maximum Wire Size AWG | 12 AWG | |
| Insulation | Insulated | |
| Colour | Clear | |
| Insulation Material | Polycarbonate | |
| Series | 221 | |
| Contact Material | Electrolytic Copper | |
| Termination Type | Push-in | |
| Contact Plating | Tin | |
| Standards/Approvals | UL 486C, EN 60664 | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type Splice Connector | ||
Splice Type Wire Splice | ||
Overall Length 29.5mm | ||
Minimum Wire Size AWG 18 AWG | ||
Diameter 2 mm | ||
Maximum Wire Size AWG 12 AWG | ||
Insulation Insulated | ||
Colour Clear | ||
Insulation Material Polycarbonate | ||
Series 221 | ||
Contact Material Electrolytic Copper | ||
Termination Type Push-in | ||
Contact Plating Tin | ||
Standards/Approvals UL 486C, EN 60664 | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
The Wago PUSH WIRE inline splicing connector is for solid and stranded conductors up to 4 mm² with a 2-conductor configuration. It features a transparent housing and cover, suitable for temperatures up to 85°C (T85). This connector is designed for easy installation by inserting the conductor until it hits the backstop. Only electricians should use it, ensuring compliance with regulations and proper use.
Color transparent
Cover color transparent
Insulation material main housing Polycarbonate
Flammability class per UL94 V2
