Molex 19198 Insulated Male Spade Connector, Solder, 10 Tab Size 22 AWG to 18 AWG
- RS Stock No.:
- 259-2479
- Mfr. Part No.:
- 19198-0007
- Brand:
- Molex
Subtotal (1 tape of 5 units)*
£1.06
(exc. VAT)
£1.27
(inc. VAT)
FREE delivery for orders over £60.00
Last RS stock
- Final 585 unit(s), ready to ship
Units | Per unit | Per Tape* |
|---|---|---|
| 5 + | £0.212 | £1.06 |
*price indicative
- RS Stock No.:
- 259-2479
- Mfr. Part No.:
- 19198-0007
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Product Type | Spade Connector | |
| Termination Type | Solder | |
| Gender | Male | |
| Tab Size | 10 | |
| Insulation | Insulated | |
| Minimum Wire Size AWG | 22AWG | |
| Maximum Wire Size AWG | 18AWG | |
| Contact Plating | Tin | |
| Insulation Material | Nylon | |
| Standards/Approvals | UL E32244, CSA LR18689 | |
| Overall Length | 23.24mm | |
| Series | 19198 | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Product Type Spade Connector | ||
Termination Type Solder | ||
Gender Male | ||
Tab Size 10 | ||
Insulation Insulated | ||
Minimum Wire Size AWG 22AWG | ||
Maximum Wire Size AWG 18AWG | ||
Contact Plating Tin | ||
Insulation Material Nylon | ||
Standards/Approvals UL E32244, CSA LR18689 | ||
Overall Length 23.24mm | ||
Series 19198 | ||
RoHS Status: Exempt
The Molex avikrimp spade tongue terminal for 22-18 AWG wire. it is stud size 10 (m5).
Barrel type closed
Flammability 94V-0
Insulation nylon (PA)
Material - plating mating tin
Net weight 0.786/g
Packaging type adhesive tape on reel
Stud size 10 (M5)
Wire size AWG 18, 20, 22
Wire size 0.25 mm² to 1.50 mm²
