EMERSON – ASCO Solenoid Valve 18900002.48/DC, 3 Port, NC M5, 48 V dc, M5

View all Solenoid Valves

Subtotal (1 unit)*

£52.02

(exc. VAT)

£62.42

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 2 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£52.02

*price indicative

RS Stock No.:
564-243
Mfr. Part No.:
18900002.48/DC
Brand:
EMERSON ? ASCO
Find similar products by selecting one or more attributes.
Select all

Brand

EMERSON ? ASCO

Product Type

Solenoid Valve

Supply Voltage

48 V dc

Number of Ports

3

Inlet Port Size

M5

Default Valve Position

NC

Outlet Port Size

M5

Outlet Connection Type

Threaded

Inlet Thread Standard

ISO 228/1

Inlet Connection Type

Threaded

Body Material

Polyamide

Series

189

Application

Air, Inert Gas

Maximum Operating Pressure

10 bar

Minimum Operating Temperature

-10°C

Outlet Thread Standard

ISO 228/1

Maximum Operating Temperature

60°C

Standards/Approvals

EN 60529, IEC 335, CSA, UL, DIN 43650, ISO 15218 (CNOMO 06-05-80/NF E 49066,size 30), ATEX Directive 2014/34/EU

Hazardous Area Certification

ATEX Directive 2014/34/EU, CSA, UL

Maximum Closing Time

10ms

Maximum Opening Time

5ms

RoHS Status: Exempt

COO (Country of Origin):
FR
The Asco Solenoid valve belongs to the direct-operated Series 189 and features a normally open, three-way configuration. It is designed for subbase mounting and has a nominal diameter of 1.2 millimeters (6B). The valve operates at 230V with a frequency range of 50-60Hz, ensuring reliable performance.

No connector included

Equipped with Coils 4304422
