EMERSON – ASCO Solenoid Valve 18900002.24/50-60, 3 Port, NC 1/8 in M5, 24 V ac

View all Solenoid Valves

Subtotal (1 unit)*

£50.88

(exc. VAT)

£61.06

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • Plus 2 unit(s) shipping from 16 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£50.88

*price indicative

RS Stock No.:
564-237
Mfr. Part No.:
18900002.24/50-60
Brand:
EMERSON ? ASCO
Find similar products by selecting one or more attributes.
Select all

Brand

EMERSON ? ASCO

Product Type

Solenoid Valve

Supply Voltage

24 V ac

Number of Ports

3

Inlet Port Size

1/8 in M5

Default Valve Position

NC

Inlet Connection Type

1/8 in G

Inlet Thread Standard

ISO 228/1

Outlet Connection Type

G 1/8

Orifice Diameter

1.5mm

Application

Air, Inert Gas

Body Material

Polyamide

Series

189

Outlet Thread Standard

ISO 228/1

Minimum Operating Temperature

-10°C

Maximum Operating Pressure

10 bar

Maximum Operating Temperature

60°C

Standards/Approvals

IEC 335, EN 60529, ISO 15218 (CNOMO 06-05-80/NF E 49066,size 30), DIN 43650, ATEX Directive 2014/34/EU, UL, CSA

Maximum Closing Time

10ms

Maximum Opening Time

5ms

RoHS Status: Exempt

COO (Country of Origin):
FR
The Asco Solenoid valve is part of the direct-operated Series 189 and features a normally open, three-way configuration. It is designed for subbase mounting and has a nominal diameter of 1.2 millimeters (6B). The valve operates at 24V with a frequency range of 50-60Hz. It is equipped with a manual override for enhanced control in various applications.

Includes Coils 4304416

Manual override provided
