EMERSON ? ASCO Solenoid Valve 18900011.48/50-60, 3 port(s) , NO, 48 V, 3/4in
- RS Stock No.:
- 432-361
- Mfr. Part No.:
- 18900011.48/50-60
- Brand:
- EMERSON ? ASCO
Subtotal (1 unit)*
£59.01
(exc. VAT)
£70.81
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £59.01 |
*price indicative
- RS Stock No.:
- 432-361
- Mfr. Part No.:
- 18900011.48/50-60
- Brand:
- EMERSON ? ASCO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | EMERSON ? ASCO | |
Supply Voltage | 48 V | |
Number of Ports | 3 | |
Connection Size | 3/4in | |
Connection | 3/4 in G | |
Operation | Direct | |
Default Valve Position | NO | |
Suitable Applications | Air, Inert Gas | |
Type | Solenoid | |
Orifice Diameter | 1.2mm | |
Body Material | Polyamide | |
Series | 189 | |
Maximum Working Pressure | 10 bar | |
Operating Temperature Range | -10 → +60 °C | |
Servo Assist | No | |
Minimum Operating Temperature | -10°C | |
Maximum Operating Temperature | +60°C | |
Thread Standard or Connection Type | G | |
Flow Factor Kv | 1.2L/min | |
Select all | ||
---|---|---|
Brand EMERSON ? ASCO | ||
Supply Voltage 48 V | ||
Number of Ports 3 | ||
Connection Size 3/4in | ||
Connection 3/4 in G | ||
Operation Direct | ||
Default Valve Position NO | ||
Suitable Applications Air, Inert Gas | ||
Type Solenoid | ||
Orifice Diameter 1.2mm | ||
Body Material Polyamide | ||
Series 189 | ||
Maximum Working Pressure 10 bar | ||
Operating Temperature Range -10 → +60 °C | ||
Servo Assist No | ||
Minimum Operating Temperature -10°C | ||
Maximum Operating Temperature +60°C | ||
Thread Standard or Connection Type G | ||
Flow Factor Kv 1.2L/min | ||
RoHS Status: Exempt
- COO (Country of Origin):
- FR
The Asco solenoid valve offers exemplary performance across diverse applications, ensuring efficient fluid control while adhering to industry standards. Designed for optimal functionality, it features a compact and lightweight construction that simplifies installation on subbases or individual setups. Its innovative design allows for AC/DC interchangeability without the need for disassembly, facilitating easier servicing. Built to withstand demanding environments, this valve is fully compliant with EU directives and is suitable for use with air and inert gases across varied temperature ranges. The robust materials used in its construction ensure durability and longevity, making it a reliable choice for professionals seeking performance and innovation.
Compact design allows for simplified installation and space-saving solutions
AC/DC interchangeable solenoid operator enhances operational versatility
Integrated visual indication supports user-friendly operations and troubleshooting
Precision-engineered seals ensure compatibility with various media
Moulded enclosure provides excellent protection against environmental factors
Manual operator feature allows for emergency control when needed
Industry-standard connector specification simplifies integration with existing systems
Designed to operate efficiently across a broad temperature spectrum
AC/DC interchangeable solenoid operator enhances operational versatility
Integrated visual indication supports user-friendly operations and troubleshooting
Precision-engineered seals ensure compatibility with various media
Moulded enclosure provides excellent protection against environmental factors
Manual operator feature allows for emergency control when needed
Industry-standard connector specification simplifies integration with existing systems
Designed to operate efficiently across a broad temperature spectrum
