Nexperia 100 V 2.8 A Rectifier & Schottky Diode Schottky 2-Pin SOD-323 PMEG100T20ELXD-QX

View this category
Bulk discount available

Subtotal (1 pack of 25 units)*

£6.40

(exc. VAT)

£7.675

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 250 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
25 - 25£0.256£6.40
50 - 75£0.252£6.30
100 - 475£0.186£4.65
500 - 1975£0.18£4.50
2000 +£0.177£4.43

*price indicative

Packaging Options:
RS Stock No.:
260-4710
Mfr. Part No.:
PMEG100T20ELXD-QX
Brand:
Nexperia
Find similar products by selecting one or more attributes.
Select all

Brand

Nexperia

Mount Type

Surface

Product Type

Rectifier & Schottky Diode

Package Type

SOD-323

Maximum Continuous Forward Current If

2.8A

Peak Reverse Repetitive Voltage Vrrm

100V

Diode Configuration

Single

Series

PMEG

Rectifier Type

Schottky

Pin Count

2

Peak Non-Repetitive Forward Surge Current Ifsm

33A

Peak Reverse Current Ir

0.75mA

Minimum Operating Temperature

-55°C

Maximum Forward Voltage Vf

880mV

Maximum Operating Temperature

175°C

Peak Reverse Recovery Time trr

36ns

Height

0.68mm

Length

2.2mm

Width

1.3 mm

Standards/Approvals

AEC-Q101

Automotive Standard

AEC-Q101

COO (Country of Origin):
MY
The Nexperia trench schottky barrier rectifier encapsulated in a CFP2-HP power flat lead surface mounted device plastic package.

High power capability due to clip-bonding technology

Power flat lead plastic package with exposed heatsink for optimal thermal connection
