Nexperia 60 V 2.8 A Rectifier & Schottky Diode Schottky Barrier 2-Pin SOD-323 PMEG60T20ELXD-QX

View this category
Bulk discount available

Subtotal (1 pack of 25 units)*

£6.40

(exc. VAT)

£7.675

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 2,125 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
25 - 25£0.256£6.40
50 - 75£0.252£6.30
100 - 475£0.185£4.63
500 - 1975£0.18£4.50
2000 +£0.177£4.43

*price indicative

Packaging Options:
RS Stock No.:
260-4725
Mfr. Part No.:
PMEG60T20ELXD-QX
Brand:
Nexperia
Find similar products by selecting one or more attributes.
Select all

Brand

Nexperia

Product Type

Rectifier & Schottky Diode

Mount Type

Surface

Package Type

SOD-323

Maximum Continuous Forward Current If

2.8A

Peak Reverse Repetitive Voltage Vrrm

60V

Series

PMEG60T20ELXD-Q

Diode Configuration

Trench Schottky Barrier Rectifier

Rectifier Type

Schottky Barrier

Pin Count

2

Maximum Forward Voltage Vf

700mV

Peak Non-Repetitive Forward Surge Current Ifsm

35A

Minimum Operating Temperature

-55°C

Peak Reverse Current Ir

0.55mA

Peak Reverse Recovery Time trr

8ns

Maximum Operating Temperature

175°C

Height

0.68mm

Standards/Approvals

AEC-Q101

Length

2.2mm

Width

1.3 mm

Automotive Standard

AEC-Q101

COO (Country of Origin):
MY
The Nexperia trench schottky barrier rectifier encapsulated in a CFP2-HP power flat lead surface mounted device plastic package.

High power capability due to clip-bonding technology

Power flat lead plastic package with exposed heatsink for optimal thermal connection
