Infineon 650 V 16 A Rectifier & Schottky Diode 3-Pin PG-TO-247 IDW16G65C5XKSA1

RS Stock No.:: 258-0978
Mfr. Part No.:: IDW16G65C5XKSA1
Brand:: Infineon

Infineon 650 V 16 A Rectifier & Schottky Diode 3-Pin PG-TO-247 IDW16G65C5XKSA1

Subtotal (1 unit)*

£1.90

(exc. VAT)

£2.28

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

2 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£1.90

*price indicative

RS Stock No.:: 258-0978
Mfr. Part No.:: IDW16G65C5XKSA1
Brand:: Infineon

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Infineon
	Mount Type	Through Hole
	Product Type	Rectifier & Schottky Diode
	Package Type	PG-TO-247
	Maximum Continuous Forward Current If	16A
	Peak Reverse Repetitive Voltage Vrrm	650V
	Series	IDW16G65C5
	Pin Count	3
	Peak Non-Repetitive Forward Surge Current Ifsm	95A
	Maximum Forward Voltage Vf	1.7V
	Minimum Operating Temperature	-55°C
	Maximum Operating Temperature	175°C
	Standards/Approvals	J-STD20 and JESD22
	Automotive Standard	No

	Select all
	Brand Infineon
	Mount Type Through Hole
	Product Type Rectifier & Schottky Diode
	Package Type PG-TO-247
	Maximum Continuous Forward Current If 16A
	Peak Reverse Repetitive Voltage Vrrm 650V
	Series IDW16G65C5
	Pin Count 3
	Peak Non-Repetitive Forward Surge Current Ifsm 95A
	Maximum Forward Voltage Vf 1.7V
	Minimum Operating Temperature -55°C
	Maximum Operating Temperature 175°C
	Standards/Approvals J-STD20 and JESD22
	Automotive Standard No

Datasheet - IDW16G65C5XKSA1

The Infineon ThinQ generation 5 represents leading edge technology for the SiC Schottky barrier diodes. Thanks to the more compact design and thin wafer technology, the new family of products shows improved efficiency over all load conditions, resulting from both the improved thermal characteristics and a lower figure of merit. The new thinQ Generation 5 has been designed to complement our 650V CoolMOS families this ensures meeting the most stringent application requirements in this voltage range.

Benchmark switching behaviour

No reverse recovery/ No forward recovery

Temperature independent switching behaviour

High surge current capability

Pb-free lead plating; RoHS compliant

Higher system reliability due to lower operating temperatures

Reduced EMI
