onsemi 800V 1A, Diode, 2-Pin DO-214AC S1K
- RS Stock No.:
- 186-7553
- Mfr. Part No.:
- S1K
- Brand:
- onsemi
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 186-7553
- Mfr. Part No.:
- S1K
- Brand:
- onsemi
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | onsemi | |
Mounting Type | Surface Mount | |
Package Type | DO-214AC (SMA) | |
Maximum Continuous Forward Current | 1A | |
Peak Reverse Repetitive Voltage | 800V | |
Diode Configuration | Single | |
Pin Count | 2 | |
Number of Elements per Chip | 1 | |
Peak Reverse Recovery Time | 1.8 (Typ.)ns | |
Peak Non-Repetitive Forward Surge Current | 30A | |
Select all | ||
---|---|---|
Brand onsemi | ||
Mounting Type Surface Mount | ||
Package Type DO-214AC (SMA) | ||
Maximum Continuous Forward Current 1A | ||
Peak Reverse Repetitive Voltage 800V | ||
Diode Configuration Single | ||
Pin Count 2 | ||
Number of Elements per Chip 1 | ||
Peak Reverse Recovery Time 1.8 (Typ.)ns | ||
Peak Non-Repetitive Forward Surge Current 30A | ||
In the world of commodity rectifiers, Fairchild Semiconductors S1 family of 1 A, P-I-N, SMA rectifiers stand out for their optimized low leakage, low capacitance, and fast response time. This was achieved while maintaining the industry standard VF max of 1.1 V at 1 A and a 30 A surge rating. In todays world, where system power efficiency is a critical differentiating feature, these advantages can be leveraged to support those higher efficiency goals.
1AIF(AV) Current Rating
Low Leakage: - 1 μA Maximum at 25°C - 50 μA Maximum at 125°C
Fast Response: 1.8 μs (Typical)
30 A Surge Rating
50 to 1000 V Reverse Voltage Ratings
6.6 pF Typical Capacitance
Low Leakage: - 1 μA Maximum at 25°C - 50 μA Maximum at 125°C
Fast Response: 1.8 μs (Typical)
30 A Surge Rating
50 to 1000 V Reverse Voltage Ratings
6.6 pF Typical Capacitance
