NTN 23120EAKW33C3 Tapered 100 mm ID Spherical Roller Bearing, 165 mm OD
- RS Stock No.:
- 640-286
- Mfr. Part No.:
- 23120EAKW33C3
- Brand:
- NTN
Subtotal (1 unit)*
£345.02
(exc. VAT)
£414.02
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 02 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £345.02 |
*price indicative
- RS Stock No.:
- 640-286
- Mfr. Part No.:
- 23120EAKW33C3
- Brand:
- NTN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | NTN | |
| Product Type | Spherical Roller Bearing | |
| Inside Diameter | 100mm | |
| Race Width | 52mm | |
| Bore Type | Tapered | |
| Cage Material | Steel | |
| Maximum Speed - Oil | 3000rpm | |
| Maximum Speed - Grease | 2400rpm | |
| Limiting Speed | 3900rpm | |
| Outside Diameter | 165mm | |
| End Type | Open | |
| Standards/Approvals | No | |
| Number of Rows | 2 | |
| Static Load Rating | 563kN | |
| Internal Clearance | C3 | |
| Dynamic Load Rating | 464kN | |
| Series | 231 | |
| Bearing Material | Through Hardened Steel | |
| Select all | ||
|---|---|---|
Brand NTN | ||
Product Type Spherical Roller Bearing | ||
Inside Diameter 100mm | ||
Race Width 52mm | ||
Bore Type Tapered | ||
Cage Material Steel | ||
Maximum Speed - Oil 3000rpm | ||
Maximum Speed - Grease 2400rpm | ||
Limiting Speed 3900rpm | ||
Outside Diameter 165mm | ||
End Type Open | ||
Standards/Approvals No | ||
Number of Rows 2 | ||
Static Load Rating 563kN | ||
Internal Clearance C3 | ||
Dynamic Load Rating 464kN | ||
Series 231 | ||
Bearing Material Through Hardened Steel | ||
Non Compliant
- COO (Country of Origin):
- IT
The NTN Spherical Roller Bearing is designed to withstand substantial loads and misalignments, making it ideal for demanding operating conditions. This type of bearing excels in environments such as crushers, vibrating screens, and heavy handling applications. With NTN's ULTAGE design, it delivers exceptional durability and extended service life as a standard feature, offering unparalleled endurance and reliability in harsh conditions.
High impacts resistance
High vibrations resistance
