SKF RNA 6909 52 mm ID Roller Bearing Cylindrical Roller, 68 mm OD
- RS Stock No.:
- 464-778
- Mfr. Part No.:
- RNA 6909
- Brand:
- SKF
Subtotal (1 unit)*
£100.21
(exc. VAT)
£120.25
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 14 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £100.21 |
*price indicative
- RS Stock No.:
- 464-778
- Mfr. Part No.:
- RNA 6909
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Roller Bearing | |
| Inside Diameter | 52mm | |
| Race Width | 40mm | |
| Cage Material | Sheet Steel | |
| Number of Rows | 2 | |
| Bearing Material | Steel | |
| Dynamic Load Rating | 81.5kN | |
| Limiting Speed | 8500rpm | |
| Static Load Rating | 137kN | |
| Outside Diameter | 68mm | |
| Series | RNA 6909 | |
| Standards/Approvals | RoHS | |
| Bearing Type | Cylindrical Roller | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Roller Bearing | ||
Inside Diameter 52mm | ||
Race Width 40mm | ||
Cage Material Sheet Steel | ||
Number of Rows 2 | ||
Bearing Material Steel | ||
Dynamic Load Rating 81.5kN | ||
Limiting Speed 8500rpm | ||
Static Load Rating 137kN | ||
Outside Diameter 68mm | ||
Series RNA 6909 | ||
Standards/Approvals RoHS | ||
Bearing Type Cylindrical Roller | ||
The SKF Double row needle roller bearings without an inner ring consist of an outer ring with two needle roller and cage assemblies. They are an excellent choice for compact bearing arrangements in applications where hardened and ground raceways can be provided on the shaft. The outer ring includes flanges to guide the roller and cage assemblies and has features to facilitate relubrication. The roller and cage assemblies and the outer ring form a non-separable unit.
High radial load carrying capacity
High stiffness
Low cross-sectional height
Accommodate axial displacement in both directions
Enable a larger shaft diameter and a more rigid bearing arrangement
