SKF RNA 4916 90 mm ID Roller Bearing Cylindrical Roller, 110 mm OD
- RS Stock No.:
- 463-490
- Mfr. Part No.:
- RNA 4916
- Brand:
- SKF
Subtotal (1 unit)*
£160.96
(exc. VAT)
£193.15
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 25 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £160.96 |
*price indicative
- RS Stock No.:
- 463-490
- Mfr. Part No.:
- RNA 4916
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Roller Bearing | |
| Inside Diameter | 90mm | |
| Race Width | 30mm | |
| Cage Material | Sheet Steel | |
| Limiting Speed | 5000rpm | |
| Standards/Approvals | RoHS | |
| Outside Diameter | 110mm | |
| Static Load Rating | 183kN | |
| Number of Rows | 1 | |
| Bearing Material | Steel | |
| Dynamic Load Rating | 102kN | |
| Series | RNA 4916 | |
| Bearing Type | Cylindrical Roller | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Roller Bearing | ||
Inside Diameter 90mm | ||
Race Width 30mm | ||
Cage Material Sheet Steel | ||
Limiting Speed 5000rpm | ||
Standards/Approvals RoHS | ||
Outside Diameter 110mm | ||
Static Load Rating 183kN | ||
Number of Rows 1 | ||
Bearing Material Steel | ||
Dynamic Load Rating 102kN | ||
Series RNA 4916 | ||
Bearing Type Cylindrical Roller | ||
- COO (Country of Origin):
- SK
The SKF Single row needle roller bearings without an inner ring consist of an outer ring with a needle roller and cage assembly. They are an excellent choice for compact bearing arrangements in applications where hardened and ground raceways can be provided on the shaft. The outer ring includes two integral flanges to guide the bearing axially and an annular groove with one or more lubrication holes to facilitate relubrication.
High radial load carrying capacity
High stiffness
Low cross sectional height
Accommodate axial displacement in both directions
