SKF 24026-2CS5/VT143 Cylindrical 130 mm ID Roller Bearing, 200 mm OD
- RS Stock No.:
- 462-185
- Mfr. Part No.:
- 24026-2CS5/VT143
- Brand:
- SKF
Subtotal (1 unit)*
£1,117.05
(exc. VAT)
£1,340.46
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 10 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,117.05 |
*price indicative
- RS Stock No.:
- 462-185
- Mfr. Part No.:
- 24026-2CS5/VT143
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Roller Bearing | |
| Inside Diameter | 130mm | |
| Race Width | 69mm | |
| Bore Type | Cylindrical | |
| Cage Material | Sheet Metal | |
| Number of Rows | 2 | |
| Static Load Rating | 815kN | |
| Internal Clearance | CN | |
| Outside Diameter | 200mm | |
| Standards/Approvals | UNSPSC, eClass, RoHS | |
| Limiting Speed | 3000rpm | |
| Race Type | Cylindrical | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Roller Bearing | ||
Inside Diameter 130mm | ||
Race Width 69mm | ||
Bore Type Cylindrical | ||
Cage Material Sheet Metal | ||
Number of Rows 2 | ||
Static Load Rating 815kN | ||
Internal Clearance CN | ||
Outside Diameter 200mm | ||
Standards/Approvals UNSPSC, eClass, RoHS | ||
Limiting Speed 3000rpm | ||
Race Type Cylindrical | ||
- COO (Country of Origin):
- SE
Omkar
The SKF Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. Under normal operating conditions, sealed bearings are almost maintenance-free, keeping service costs and grease consumption low. The design includes features to facilitate relubrication.
Accommodate misalignment
High load carrying capacity
Sealed for increased reliability, with relubrication features
Low friction and long service life
Increased wear resistance
