SKF 32038 X Taper Roller 190 mm ID Tapered Roller Bearing, 290 mm OD
- RS Stock No.:
- 461-956
- Mfr. Part No.:
- 32038 X
- Brand:
- SKF
Subtotal (1 unit)*
£1,598.41
(exc. VAT)
£1,918.09
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 25 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,598.41 |
*price indicative
- RS Stock No.:
- 461-956
- Mfr. Part No.:
- 32038 X
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Tapered Roller Bearing | |
| Inside Diameter | 190mm | |
| Bore Type | Cylindrical | |
| Cage Material | Sheet Metal | |
| Cone Width | 64mm | |
| Number of Rows | 1 | |
| Cup Width | 48mm | |
| Static Load Rating | 2400kN | |
| Outside Diameter | 290mm | |
| Bearing Dynamic Load Rating | 806kN | |
| Standards/Approvals | eClass, RoHS, UNSPSC | |
| Limiting Speed | 2000rpm | |
| Bearing Type | Taper Roller | |
| Race Type | Cylindrical | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Tapered Roller Bearing | ||
Inside Diameter 190mm | ||
Bore Type Cylindrical | ||
Cage Material Sheet Metal | ||
Cone Width 64mm | ||
Number of Rows 1 | ||
Cup Width 48mm | ||
Static Load Rating 2400kN | ||
Outside Diameter 290mm | ||
Bearing Dynamic Load Rating 806kN | ||
Standards/Approvals eClass, RoHS, UNSPSC | ||
Limiting Speed 2000rpm | ||
Bearing Type Taper Roller | ||
Race Type Cylindrical | ||
Omkar
The SKF Single row tapered roller bearings are designed to accommodate combined radial and axial loads and provide low friction during operation. The inner ring, with rollers and cage, can be mounted separately from the outer ring. These separable and interchangeable components facilitate mounting, dismounting and maintenance. By mounting one single row tapered roller bearing against another and applying a preload, a rigid bearing application can be achieved.
High radial and axial load carrying capacity
Accommodate axial loads in one direction
Low friction and long service life
Separable and interchangeable components
