FAG 22319-E1-XL-C3 Cylindrical 95 mm ID Spherical Roller Bearing, 200 mm OD
- RS Stock No.:
- 310-462
- Mfr. Part No.:
- 22319-E1-XL-C3
- Brand:
- FAG
Subtotal (1 unit)*
£524.17
(exc. VAT)
£629.00
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 02 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £524.17 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 310-462
- Mfr. Part No.:
- 22319-E1-XL-C3
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | FAG | |
| Product Type | Spherical Roller Bearing | |
| Inside Diameter | 95mm | |
| Race Width | 67mm | |
| Bore Type | Cylindrical | |
| Cage Material | Carbon Steel | |
| Standards/Approvals | RoHS, DIN 635-2 | |
| Series | 223E1 | |
| Internal Clearance | C3 | |
| Static Load Rating | 700000N | |
| Limiting Speed | 3700rpm | |
| Outside Diameter | 200mm | |
| Dynamic Load Rating | 670000N | |
| Bearing Material | Steel | |
| Number of Rows | 2 | |
| Better World Product | Yes | |
| Better World Claim | Extended Product Life, Saves Energy | |
| Select all | ||
|---|---|---|
Brand FAG | ||
Product Type Spherical Roller Bearing | ||
Inside Diameter 95mm | ||
Race Width 67mm | ||
Bore Type Cylindrical | ||
Cage Material Carbon Steel | ||
Standards/Approvals RoHS, DIN 635-2 | ||
Series 223E1 | ||
Internal Clearance C3 | ||
Static Load Rating 700000N | ||
Limiting Speed 3700rpm | ||
Outside Diameter 200mm | ||
Dynamic Load Rating 670000N | ||
Bearing Material Steel | ||
Number of Rows 2 | ||
Better World Product Yes | ||
Better World Claim Extended Product Life, Saves Energy | ||
- COO (Country of Origin):
- DE
The FAG Spherical Roller Bearing is designed to deliver superior performance in high-load applications. Its advanced construction features a cage made of sheet metal, ensuring robust support while allowing for reliable operation under varying conditions. The product is engineered to accommodate radial loads, making it ideal for applications where both dynamic loading and misalignment are factors.
Dynamic and static axial load factors enhance operational efficiency
Optimised design limits fatigue under heavy stress promoting longevity
Easy integration into existing systems ensuring quick and reliable installation
