- RS Stock No.:
- 734-6930
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Contact Configuration | DPDT | |
Switch Operation | On-(On) | |
Panel Cut Out Width | 7mm | |
Panel Cut Out Height | 5.15mm | |
Contact Current Rating | 400 mA | |
Illuminated | No | |
Actuator Colour | Black | |
Mounting Type | Panel Mount | |
Terminal Type | Right Angle PC Pin | |
Actuator Shape | Rectangular | |
Panel Cut Out Size | 5.15 x 7mm | |
Mechanical Life | 50000Operations | |
Operating Temperature Range | -30 → +85°C | |
Contact Resistance | 100mΩ | |
Minimum Operating Temperature | -30°C | |
Contact Material | Gold Plated Copper Alloy | |
Case Material | Glass Fibre Reinforced Nylon | |
Maximum Operating Temperature | +85°C | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Contact Configuration DPDT | ||
Switch Operation On-(On) | ||
Panel Cut Out Width 7mm | ||
Panel Cut Out Height 5.15mm | ||
Contact Current Rating 400 mA | ||
Illuminated No | ||
Actuator Colour Black | ||
Mounting Type Panel Mount | ||
Terminal Type Right Angle PC Pin | ||
Actuator Shape Rectangular | ||
Panel Cut Out Size 5.15 x 7mm | ||
Mechanical Life 50000Operations | ||
Operating Temperature Range -30 → +85°C | ||
Contact Resistance 100mΩ | ||
Minimum Operating Temperature -30°C | ||
Contact Material Gold Plated Copper Alloy | ||
Case Material Glass Fibre Reinforced Nylon | ||
Maximum Operating Temperature +85°C | ||
- COO (Country of Origin):
- TW
RS PRO DPDT Latching Rocker Switch
Introducing the RS PRO range of miniature and sub-miniature rocker switches with a variety of configurations for greater flexibility across different environments and applications. These mini rocker switches are available with SPDT (Single Pole, Double Throw) and DPDT (Double Pole, Double Throw) contact structure options covering the needs for most applications when these are required. These switches also feature gold plated copper alloy contacts with a mechanical life of 40,000 make and break cycles and have a ULV94V0 case material with tin plates brass switch supports.
Features and Benefits:
• Each switch has a mechanical life of 40,000 make or break cycles
• The housing and base is made from glass-filled nylon 6/6 or 4/6 allowing for it to be flame retardant and heat stabilised (UL94V-0) for optimum performance in the harshest environments and applications
• The contact terminals are made with gold plated copper alloy providing outstanding resistance to corrosion and allows for high thermal and electrical conductivity
• The switch supports are made from brass with tin plating for greater durability when exposed to high functioning environments or applications
• RoHS compliant
• The housing and base is made from glass-filled nylon 6/6 or 4/6 allowing for it to be flame retardant and heat stabilised (UL94V-0) for optimum performance in the harshest environments and applications
• The contact terminals are made with gold plated copper alloy providing outstanding resistance to corrosion and allows for high thermal and electrical conductivity
• The switch supports are made from brass with tin plating for greater durability when exposed to high functioning environments or applications
• RoHS compliant
What is a rocker switch?
A rocker switch provides an on/off facility that 'rocks' rather than trips when pressed, meaning one side of the switch is always raised. It often looks like a rocking horse rocking backwards and forwards hence the name 'rocker' switch. It often has a circle for ON on one end and a horizontal dash or line for the OFF side to clearly indicate to the user what status the device is on.
Where are rocker switches used?
Rocker switches can be used in a variety of applications like surge protectors, display monitors, computer power supplies, plus much more.
Rocker Switches - RS
The RS range of Miniature and Sub-Miniature Rockers Switches are available in a variety of Contact and Switch configurations.
