Eaton PKN6/M RCD, 6A, 2 Pole, 30mA, Type C, 230V ac
- RS Stock No.:
- 922-8698
- Mfr. Part No.:
- 236017 PKNM-6/1N/C/003-MW
- Brand:
- Eaton
Subtotal (1 unit)*
£133.30
(exc. VAT)
£159.96
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 6 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £133.30 |
*price indicative
- RS Stock No.:
- 922-8698
- Mfr. Part No.:
- 236017 PKNM-6/1N/C/003-MW
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Circuit Breaker Type | RCD | |
| Current Rating | 6A | |
| Number of Poles | 2 | |
| Range | PKNM | |
| Trip Sensitivity | 30mA | |
| Tripping Characteristics | Type C | |
| Voltage Rating | 230V ac | |
| Series | PKN6/M | |
| Standards Met | CE | |
| Overall Width | 35mm | |
| Rated AC Voltage | 230V | |
| Overall Length | 75mm | |
| Application | Commercial, Residential | |
| Overall Dimensions | 35 x 75 x 80mm | |
| Terminal Contact Type | Screw | |
| Mounting Style | DIN Rail Mount | |
| Earth Leakage Protection Type | AC | |
| Breaking Capacity at Maximum Voltage Rating | 10 kA | |
| Overall Depth | 80mm | |
| Reset Actuator Type | Toggle Switch | |
| Break Time | Instantaneous | |
Select all | ||
|---|---|---|
Brand Eaton | ||
Circuit Breaker Type RCD | ||
Current Rating 6A | ||
Number of Poles 2 | ||
Range PKNM | ||
Trip Sensitivity 30mA | ||
Tripping Characteristics Type C | ||
Voltage Rating 230V ac | ||
Series PKN6/M | ||
Standards Met CE | ||
Overall Width 35mm | ||
Rated AC Voltage 230V | ||
Overall Length 75mm | ||
Application Commercial, Residential | ||
Overall Dimensions 35 x 75 x 80mm | ||
Terminal Contact Type Screw | ||
Mounting Style DIN Rail Mount | ||
Earth Leakage Protection Type AC | ||
Breaking Capacity at Maximum Voltage Rating 10 kA | ||
Overall Depth 80mm | ||
Reset Actuator Type Toggle Switch | ||
Break Time Instantaneous | ||
- COO (Country of Origin):
- RO
Eaton PKN6/M Series RCD, 6A Current Rating, 30mA Trip Sensitivity - 236017 PKNM-6/1N/C/003-MW
This RCD is a vital component in electrical installations, offering effective earth leakage protection with a current rating of 6A. Designed to be mounted on a DIN rail, it measures 35 x 75 x 80 mm, making it suitable for a variety of applications. This RCD complies with CE standards, ensuring it meets safety and performance requirements in both residential and commercial environments.
Features & Benefits
• Instantaneous tripping for immediate response to faults
• Type C design suitable for commercial applications
• Robust 10kA breaking capacity for high fault current tolerance
• Simple screw terminal contacts for easy installation
• Compact design aids in efficient circuit management
• Type C design suitable for commercial applications
• Robust 10kA breaking capacity for high fault current tolerance
• Simple screw terminal contacts for easy installation
• Compact design aids in efficient circuit management
Applications
• Ideal for residential circuit protection in homes
• Used for commercial RCD solutions in retail establishments
• Effectively enhances safety measures in automated machinery environments
• Used for commercial RCD solutions in retail establishments
• Effectively enhances safety measures in automated machinery environments
What current capacity does the switch provide for protection?
The switch provides a current rating of 6A, ensuring it is effective for low-power applications and safeguarding against faults in smaller circuits.
How does the device respond to earth leakage?
It features a trip sensitivity of 30mA, which allows for rapid disconnection when a fault is detected, significantly reducing the risk of electric shocks.
What is the significance of the instantaneous tripping feature?
Instantaneous tripping eliminates the delay in disconnection during fault conditions, providing enhanced protection for individuals and equipment by swiftly mitigating risks.
What electrical environments is the device best suited for?
It is ideal for both residential and commercial use, accommodating various electrical safety requirements across different installation types.
What are the installation requirements for this RCD?
The device is designed for DIN rail mounting, ensuring easy integration into existing panel designs while maintaining a compact footprint.
Note
Eaton formerly known as Moeller
