Eaton RCD, 6A, 2 Pole, 30mA, Type B
- RS Stock No.:
- 922-8695
- Mfr. Part No.:
- 236012 PKNM-6/1N/B/003-A-MW
- Brand:
- Eaton
Subtotal (1 unit)*
£187.41
(exc. VAT)
£224.89
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 3 unit(s) ready to ship
- Plus 4 unit(s) shipping from 18 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £187.41 |
*price indicative
- RS Stock No.:
- 922-8695
- Mfr. Part No.:
- 236012 PKNM-6/1N/B/003-A-MW
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Circuit Breaker Type | RCD | |
| Current Rating | 6A | |
| Number of Poles | 2 | |
| Range | PKNM | |
| Trip Sensitivity | 30mA | |
| Tripping Characteristics | Type B | |
| Overall Dimensions | 35 x 65.5 x 80mm | |
| Overall Width | 65.5mm | |
| Overall Depth | 80mm | |
| Reset Actuator Type | Toggle Switch | |
| Terminal Contact Type | Screw | |
| Overall Length | 35mm | |
| Break Time | Instantaneous | |
| Mounting Style | DIN Rail Mount | |
| Rated AC Voltage | 230V | |
Select all | ||
|---|---|---|
Brand Eaton | ||
Circuit Breaker Type RCD | ||
Current Rating 6A | ||
Number of Poles 2 | ||
Range PKNM | ||
Trip Sensitivity 30mA | ||
Tripping Characteristics Type B | ||
Overall Dimensions 35 x 65.5 x 80mm | ||
Overall Width 65.5mm | ||
Overall Depth 80mm | ||
Reset Actuator Type Toggle Switch | ||
Terminal Contact Type Screw | ||
Overall Length 35mm | ||
Break Time Instantaneous | ||
Mounting Style DIN Rail Mount | ||
Rated AC Voltage 230V | ||
- COO (Country of Origin):
- RO
Eaton RCD/MCD - PKNM Series
Introducing Eaton's range of PKNM RCD's, a professional and high-quality range of residual current devices. Providing complete protection, these RCD's have been created and designed to protect users from a fatal electric shock through the use of the automatic switch-off of electricity where there is a fault. The device monitors the in going and outgoing current flow and trips when an imbalance occurs. These RCD's are commonly installed in applications where there are exposed wires, prone to overheating or earth faults. Each device from the PKNM range incorporates a red and green contact position indicator.
The range also features a 3 position DIN clip which is to help prevent the removal of the appliance.
Note
Eaton formerly known as Moeller
