Eaton RCBO, 20A Current Rating, 1P+N Poles, 30mA Trip Sensitivity, Type C, PXK Range
- RS Stock No.:
- 183-3546
- Mfr. Part No.:
- 236965 PXK-C20/1N/003-A
- Brand:
- Eaton
Subtotal (1 unit)*
£65.63
(exc. VAT)
£78.76
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship
- Plus 17 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £65.63 |
*price indicative
- RS Stock No.:
- 183-3546
- Mfr. Part No.:
- 236965 PXK-C20/1N/003-A
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Eaton | |
Current Rating | 20A | |
Number of Poles | 1P+N | |
Trip Sensitivity | 30mA | |
Tripping Characteristics | Type C | |
Range | PXK | |
Circuit Breaker Type | RCD | |
Rated AC Voltage | 240V | |
Earth Leakage Protection Type | A | |
Application | Commercial, Residential | |
Break Time | Instantaneous | |
Breaking Capacity at Maximum Voltage Rating | 10 kA | |
Select all | ||
---|---|---|
Brand Eaton | ||
Current Rating 20A | ||
Number of Poles 1P+N | ||
Trip Sensitivity 30mA | ||
Tripping Characteristics Type C | ||
Range PXK | ||
Circuit Breaker Type RCD | ||
Rated AC Voltage 240V | ||
Earth Leakage Protection Type A | ||
Application Commercial, Residential | ||
Break Time Instantaneous | ||
Breaking Capacity at Maximum Voltage Rating 10 kA | ||
- COO (Country of Origin):
- AT
Eaton Residual Current Circuit Breaker With Overcurrent Protection, 1+N Poles - PXK-C Series - PXK-C16/1N/003-A
This Eaton RCBO (residual current circuit breaker with overcurrent protection) provides effective protection against earth fault currents, current overloads and short circuits. The unit combines RCD (residual current device) and MCB (miniature circuit breaker) functionality to detect current imbalances and cut the power supply. This enhances workplace safety and protects personnel from electrocution and equipment from damage. Its type-C tripping characteristic means this RCBO can handle between five and ten times its rated current, so you can use it confidently in commercial and industrial applications.
• UV-protected (ultraviolet) casing makes the device robust and protects it from damage caused by direct sunlight
• 30mA high trip sensitivity means it rapidly cuts power, to prevent the risk to operators of prolonged electric shocks
• IP20 (ingress protection) prevents contact with open wires and protects against corrosive particles
• 30mA high trip sensitivity means it rapidly cuts power, to prevent the risk to operators of prolonged electric shocks
• IP20 (ingress protection) prevents contact with open wires and protects against corrosive particles
Does an RCBO trip neutral circuits?
Yes – an RCBO, like this one from Eaton, trips both live and neutral circuits. It's advisable to check the specifications of an RCBO before purchase to ensure it's suitable for your application.
Note
Eaton formerly known as Moeller
