MPN

Finder PCB Mount Power Relay, 230V ac Coil, 8A Switching Current, DPDT

RS Stock No.:: 894-9423
Distrelec Article No.:: 300-02-992
Mfr. Part No.:: 41.52.8.230.0000
Brand:: Finder

Finder PCB Mount Power Relay, 230V ac Coil, 8A Switching Current, DPDT

Bulk discount available

Subtotal (1 unit)*

£12.97

(exc. VAT)

£15.56

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

13 unit(s) ready to ship
Plus 127 unit(s) ready to ship from another location
Plus 999,999,986 unit(s) shipping from 05 November 2025

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 - 4	£12.97
5 - 9	£12.32
10 +	£11.94

*price indicative

RS Stock No.:: 894-9423
Distrelec Article No.:: 300-02-992
Mfr. Part No.:: 41.52.8.230.0000
Brand:: Finder

41 Series - 41.52, 41.31 & 41.61

PCB mount power relays with ac and dc coils.

Low profile
Flux proof, RTII
Minimum switching load 300mW
8mm creepage and clearance between coil and contacts
Dimensions 15.7x12.5x29 mm

Approvals

UL (Canada & US); VDE

Finder 41 Series Power Relay, 230V AC Coil Voltage, 8A Switching Current - 41.52.8.230.0000

This power relay is a low-profile PCB mount device designed for efficient control in various applications. It operates at a coil voltage of 230V AC and features a DPDT configuration, making it suitable for versatile tasks. With dimensions of 29 x 12.6 x 15.7mm, this relay ensures effective performance in compact spaces.

Features & Benefits

• Capable of switching currents up to 8A for multiple applications
• High voltage isolation of 6kV enhances system reliability
• Designed with a silver alloy contact material for prolonged life
• Meets multiple standards, ensuring compliance and safety
• Exceptional mechanical life rated at 60,000 cycles improves durability
• Low power coil consumption of 0.4W increases energy efficiency

Applications

• Utilised in building automation systems for reliable control
• Ideal for timers and lighting controls to enhance user convenience
• Employed in industrial robots for precise operation
• Essential in door and gate openers for automated functionality
• Perfect for electronic circuit boards needing robust switching solutions

What everyday scenarios can this relay effectively manage?

It can manage various control systems, including automated lighting and complex machinery operations, providing reliable switching as needed.

How does the high voltage isolation specification enhance performance?

The 6kV isolation protects sensitive components from surges, thus improving the overall reliability and safety of electrical systems.

What benefits does the silver alloy contact material offer?

This contact material ensures lower wear and enhanced conductivity, which ultimately extends the relay's operational life and efficiency.

In what temperature ranges can this relay operate effectively?

This relay functions within a temperature range of -40°C to +70°C, making it suitable for both extreme and regular environments.

How does the mechanical life compare with other relays?

With a mechanical life rating of 60,000 cycles, it significantly outperforms many standard relays, resulting in fewer replacements and maintenance needs.

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Finder
	Coil Voltage	230V ac
	Contact Configuration	DPDT
	Mounting Type	PCB Mount
	Switching Current	8A
	Number of Poles	2
	Series	41 Series
	Terminal Type	PCB Pin
	Maximum Switching Voltage AC	400V ac
	Maximum Switching Voltage DC	110V dc
	Maximum Switching Current AC	15 A
	Length	29mm
	Coil Power	400mW
	Contact Material	Silver Alloy
	Standards Met	cULus, EAC, PCT, RINA, UL, VDE
	Depth	12.6mm
	Isolation Coil To Contact	6kV
	Maximum Operating Temperature	+70°C
	Minimum Operating Temperature	-40°C
	Height	15.7mm
	Life	60000 Cycles
	Number of Coils	Single
	Dimensions	29 x 12.6 x 15.7mm

	Select all
	Brand Finder
	Coil Voltage 230V ac
	Contact Configuration DPDT
	Mounting Type PCB Mount
	Switching Current 8A
	Number of Poles 2
	Series 41 Series
	Terminal Type PCB Pin
	Maximum Switching Voltage AC 400V ac
	Maximum Switching Voltage DC 110V dc
	Maximum Switching Current AC 15 A
	Length 29mm
	Coil Power 400mW
	Contact Material Silver Alloy
	Standards Met cULus, EAC, PCT, RINA, UL, VDE
	Depth 12.6mm
	Isolation Coil To Contact 6kV
	Maximum Operating Temperature +70°C
	Minimum Operating Temperature -40°C
	Height 15.7mm
	Life 60000 Cycles
	Number of Coils Single
	Dimensions 29 x 12.6 x 15.7mm
