Omron PCB Mount Latching Power Relay, 12V dc Coil, 5A Switching Current, SPDT
- RS Stock No.:
- 683-8747
- Mfr. Part No.:
- G2RK-1 DC12
- Brand:
- Omron
253 In stock - FREE next working day delivery available
Added
Price Each
£5.51
(exc. VAT)
£6.61
(inc. VAT)
| Units | Per unit |
| 1 - 9 | £5.51 |
| 10 - 49 | £4.87 |
| 50 - 99 | £4.18 |
| 100 - 249 | £3.82 |
| 250 + | £3.61 |
- RS Stock No.:
- 683-8747
- Mfr. Part No.:
- G2RK-1 DC12
- Brand:
- Omron
Technical Reference
Legislation and Compliance
Product Details
G2R Series
General purpose PCB power relay used in various domestic and commercial applications
8mm creepage/clearance
H25.5 x W13 x D29 mm
8mm creepage/clearance
H25.5 x W13 x D29 mm
Approvals
UL508; CSA22.2; EN 61810-1; SEV; SEMKO
Specifications
Attribute | Value |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | SPDT |
| Mounting Type | PCB Mount |
| Switching Current | 5A |
| Latching | Yes |
| Terminal Type | Through Hole |
| Maximum Switching Voltage AC | 380V ac |
| Maximum Switching Voltage DC | 125V dc |
| Length | 29mm |
| Coil Resistance | 170 (Set Coil) Ω, 240 (Reset Coil) Ω |
| Contact Material | Silver |
| Maximum Operating Temperature | +70°C |
| Height | 25.5mm |
| Depth | 13mm |
| Minimum Operating Temperature | -40°C |
| Maximum Switching Power AC | 1.25 kVA |
| Maximum Switching Power DC | 150 W |
| Dimensions | 29 x 25.5 x 13mm |
| Application | Power |
