Omron PCB Mount Latching Power Relay, 24V dc Coil, 5A Switching Current, SPDT
- RS Stock No.:
- 683-8741
- Mfr. Part No.:
- G2RK-1 DC24
- Brand:
- Omron
Bulk discount available
Subtotal (1 unit)*
£10.00
(exc. VAT)
£12.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 33 unit(s) ready to ship
- Plus 1 unit(s) ready to ship from another location
- Plus 163 unit(s) shipping from 28 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 9 | £10.00 |
10 - 49 | £9.47 |
50 - 99 | £9.02 |
100 - 249 | £8.58 |
250 + | £8.14 |
*price indicative
- RS Stock No.:
- 683-8741
- Mfr. Part No.:
- G2RK-1 DC24
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Omron | |
Coil Voltage | 24V dc | |
Contact Configuration | SPDT | |
Mounting Type | PCB Mount | |
Switching Current | 5A | |
Latching | Yes | |
Terminal Type | Through Hole | |
Maximum Switching Voltage AC | 380V ac | |
Maximum Switching Voltage DC | 125V dc | |
Length | 29mm | |
Coil Resistance | 694 (Set Coil) Ω, 960 (Reset Coil) Ω | |
Contact Material | Silver | |
Maximum Operating Temperature | +70°C | |
Depth | 13mm | |
Height | 25.5mm | |
Minimum Operating Temperature | -40°C | |
Maximum Switching Power DC | 150 W | |
Maximum Switching Power AC | 1.25 kVA | |
Dimensions | 29 x 25.5 x 13mm | |
Application | Power | |
Select all | ||
---|---|---|
Brand Omron | ||
Coil Voltage 24V dc | ||
Contact Configuration SPDT | ||
Mounting Type PCB Mount | ||
Switching Current 5A | ||
Latching Yes | ||
Terminal Type Through Hole | ||
Maximum Switching Voltage AC 380V ac | ||
Maximum Switching Voltage DC 125V dc | ||
Length 29mm | ||
Coil Resistance 694 (Set Coil) Ω, 960 (Reset Coil) Ω | ||
Contact Material Silver | ||
Maximum Operating Temperature +70°C | ||
Depth 13mm | ||
Height 25.5mm | ||
Minimum Operating Temperature -40°C | ||
Maximum Switching Power DC 150 W | ||
Maximum Switching Power AC 1.25 kVA | ||
Dimensions 29 x 25.5 x 13mm | ||
Application Power | ||
- COO (Country of Origin):
- JP

Omron PCB Power Relay
The Omron PCB power relay has a single pole and switching current rating of 5A. This DC powered PCB power relay has double winding latching. It has a safety-oriented design with a dielectric strength of 5kV between coil and contacts. Its surge resistance is 10kV.
Features and Benefits
24VDC supply rated coil
Flux protected enclosure
Operating temperature ranging between -40°C and 70°C
SPDT contact configuration
Flux protected enclosure
Operating temperature ranging between -40°C and 70°C
SPDT contact configuration
Applications
Anti-condensation equipment
Car washing equipment
Coffee machines
Commercial cooking equipment
Driers and pumps
HVAC
Industrial cleaning equipment
Refrigeration
Car washing equipment
Coffee machines
Commercial cooking equipment
Driers and pumps
HVAC
Industrial cleaning equipment
Refrigeration
Certifications
CSA certified
UL approved
VDE certified
UL approved
VDE certified
