Finder DIN Rail Modular Step Relay, 230V ac Coil, 16A Switching Current, 1NO/1NC
- RS Stock No.:
- 286-4995
- Distrelec Article No.:
- 136-70-167
- Mfr. Part No.:
- 202382304000
- Brand:
- Finder
Subtotal (1 unit)*
£31.69
(exc. VAT)
£38.03
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 6 unit(s) ready to ship
- Plus 12 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £31.69 |
*price indicative
- RS Stock No.:
- 286-4995
- Distrelec Article No.:
- 136-70-167
- Mfr. Part No.:
- 202382304000
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Finder | |
Coil Voltage | 230V ac | |
Contact Configuration | 1NO/1NC | |
Mounting Type | DIN Rail | |
Switching Current | 16A | |
Number of Poles | 3 | |
Series | 20 | |
Terminal Type | Screw | |
Maximum Switching Voltage AC | 400V ac | |
Maximum Switching Voltage DC | 110V dc | |
Maximum Switching Current AC | 30 A | |
Coil Power | 6.5VA | |
Maximum Operating Temperature | 40°C | |
Isolation Coil To Contact | 4kV | |
Life | 100000 Cycles | |
Minimum Operating Temperature | -40°C | |
Contact Material | Silver Alloy | |
Number of Coils | Single | |
Dimensions | 17.4 x 84 x 58.4mm | |
Select all | ||
---|---|---|
Brand Finder | ||
Coil Voltage 230V ac | ||
Contact Configuration 1NO/1NC | ||
Mounting Type DIN Rail | ||
Switching Current 16A | ||
Number of Poles 3 | ||
Series 20 | ||
Terminal Type Screw | ||
Maximum Switching Voltage AC 400V ac | ||
Maximum Switching Voltage DC 110V dc | ||
Maximum Switching Current AC 30 A | ||
Coil Power 6.5VA | ||
Maximum Operating Temperature 40°C | ||
Isolation Coil To Contact 4kV | ||
Life 100000 Cycles | ||
Minimum Operating Temperature -40°C | ||
Contact Material Silver Alloy | ||
Number of Coils Single | ||
Dimensions 17.4 x 84 x 58.4mm | ||
- COO (Country of Origin):
- FR
Finder Series 20 Modular Step Relay, 230V AC Coil Voltage, 1NO/1NC Contact Configuration - 202382304000
This modular step relay is a reliable electrical component designed for various automation applications. Features include a 230V AC relay with a 1NO and 1NC contact configuration, allowing for versatile control in complex systems. The relay is compact, measuring 17.4x84x58.4mm, making it suitable for installation on a standard 35mm DIN rail. Built for performance, it operates effectively within a wide temperature range, ensuring functionality from -40°C up to 40°C.
Features & Benefits
• Designed for DIN rail mounting for easy installation
• Supports a switching current of up to 16A for substantial loads
• Features screw terminals for secure and reliable connections
• High isolation of 4kV between coil and contacts enhances safety
• Optimised for ambient temperatures from -40°C to 40°C
• Made with AgSnO2 contact material for durability and longevity
• Supports a switching current of up to 16A for substantial loads
• Features screw terminals for secure and reliable connections
• High isolation of 4kV between coil and contacts enhances safety
• Optimised for ambient temperatures from -40°C to 40°C
• Made with AgSnO2 contact material for durability and longevity
Applications
• Used for motor control in industrial automation systems
• Ideal for switching in heating equipment
• Utilised in lighting control systems and energy management
• Suitable for use in telecommunications equipment
• Employed in safety interlock systems for machinery
• Ideal for switching in heating equipment
• Utilised in lighting control systems and energy management
• Suitable for use in telecommunications equipment
• Employed in safety interlock systems for machinery
What is the significance of the 16A switching current capacity?
The 16A switching current allows the relay to handle significant electrical loads, ensuring it can control various devices effectively without the risk of overheating or failure.
How does the isolation between the coil and contacts improve safety?
The 4kV isolation prevents electrical interference and accidental triggering, safeguarding both the circuit and connected equipment from damage and ensuring safe operation.
Can this relay handle voltage spikes during operation?
Yes, the electrical relay is designed to manage maximum switching voltages of 400V AC, making it capable of withstanding voltage spikes that can occur in electrical systems.
What installation requirements should be considered?
It must be mounted on a 35mm DIN rail, ensuring proper fit and mechanical stability for reliable operation in various environments.
What are the implications of the temperature range on its performance?
Operating efficiently between -40°C and 40°C ensures functionality in diverse settings, from cold storage facilities to warmer industrial environments, without affecting reliability.
