Finder Through Hole Power Relay, 5V Coil, 6A Switching Current, SPDT
- RS Stock No.:
- 285-8018
- Mfr. Part No.:
- 32.21.7.005.4000
- Brand:
- Finder
Subtotal (1 unit)*
£6.15
(exc. VAT)
£7.38
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 19 unit(s) shipping from 29 January 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £6.15 |
*price indicative
- RS Stock No.:
- 285-8018
- Mfr. Part No.:
- 32.21.7.005.4000
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Coil Voltage | 5V | |
| Product Type | Power Relay | |
| Contact Configuration | SPDT | |
| Mount Type | Through Hole | |
| Series | 32 | |
| Terminal Type | PCB Pin | |
| Switching Current | 6A | |
| Switching Power | 1.5kVA | |
| Minimum Operating Temperature | -40°C | |
| Coil Resistance | 125Ω | |
| Maximum Operating Temperature | 85°C | |
| Height | 10.7mm | |
| Coil Power | 0.2W | |
| Length | 20mm | |
| Standards/Approvals | No | |
| Width | 10mm | |
| Contact Material | Silver Tin Oxide | |
| Contact Resistance | 185mΩ | |
| Select all | ||
|---|---|---|
Brand Finder | ||
Coil Voltage 5V | ||
Product Type Power Relay | ||
Contact Configuration SPDT | ||
Mount Type Through Hole | ||
Series 32 | ||
Terminal Type PCB Pin | ||
Switching Current 6A | ||
Switching Power 1.5kVA | ||
Minimum Operating Temperature -40°C | ||
Coil Resistance 125Ω | ||
Maximum Operating Temperature 85°C | ||
Height 10.7mm | ||
Coil Power 0.2W | ||
Length 20mm | ||
Standards/Approvals No | ||
Width 10mm | ||
Contact Material Silver Tin Oxide | ||
Contact Resistance 185mΩ | ||
- COO (Country of Origin):
- SI
The Miniature P.C.B. relay is a high-quality product designed for sensitive DC applications. With a low profile and a wash tight design, this relay offers a 1 CO (SPDT) contact with a rated current of 6 A. It is ideal for P.C.B. mounting and offers reliable performance in a compact package.
Sensitive DC version designed for low profile applications
1 CO (SPDT) contact with a rated current of 6 A for versatile use
Wash tight design (RT III) ensures protection in challenging environments
Rated load in AC1 of 1,500 VA for reliable performance
Compact P.C.B. mounting for easy installation
