Omron PCB Mount Non-Latching Relay, 24V dc Coil, 10A Switching Current, SPST
- RS Stock No.:
- 232-6272
- Mfr. Part No.:
- G5Q-1A-HA-PW DC24 (TY)
- Brand:
- Omron
Available to back order for despatch 20/05/2025
Price Each (In a Tray of 500)
£1.528
(exc. VAT)
£1.834
(inc. VAT)
Units | Per unit | Per Tray* |
|---|---|---|
| 500 - 1000 | £1.528 | £764.00 |
| 1500 + | £1.496 | £748.00 |
*price indicative
- RS Stock No.:
- 232-6272
- Mfr. Part No.:
- G5Q-1A-HA-PW DC24 (TY)
- Brand:
- Omron
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
The Omron miniature power relay with 1-pole and 10A switching capacity. Rated coil voltage is 24Vdc and use for output applications of control equipment.
Excellent switching performance for a variety of loads
Small, yet provides 8-kV impulse withstand voltage (between coil and contacts)
Low coil power consumption (SPST-NO: 200 mW, SPDT: 400 mW)
Coil insulation system: Class F (UL1446)
IEC/EN 60335-1 confor
Small, yet provides 8-kV impulse withstand voltage (between coil and contacts)
Low coil power consumption (SPST-NO: 200 mW, SPDT: 400 mW)
Coil insulation system: Class F (UL1446)
IEC/EN 60335-1 confor
Specifications
Attribute | Value |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | SPST |
| Mounting Type | PCB Mount |
| Switching Current | 10A |
| Number of Poles | 1 |
| Coil Resistance | 2.88 kΩ |
| Coil Power | 200mW |
| Series | G5Q |
| Isolation Coil To Contact | 8kV |
| Number of Coils | Single |
