Omron PCB Mount Non-Latching Relay, 5V dc Coil, 10A Switching Current, SPST
- RS Stock No.:
- 232-6274
- Mfr. Part No.:
- G5Q-1A-HA-PW DC5 (TY)
- Brand:
- Omron
Bulk discount available
Subtotal (1 tray of 500 units)*
£764.00
(exc. VAT)
£917.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 24 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
|---|---|---|
| 500 - 1000 | £1.528 | £764.00 |
| 1500 + | £1.496 | £748.00 |
*price indicative
- RS Stock No.:
- 232-6274
- Mfr. Part No.:
- G5Q-1A-HA-PW DC5 (TY)
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Coil Voltage | 5V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 10A | |
| Number of Poles | 1 | |
| Series | G5Q | |
| Coil Resistance | 125 Ω | |
| Coil Power | 200mW | |
| Isolation Coil To Contact | 8kV | |
| Number of Coils | Single | |
Select all | ||
|---|---|---|
Brand Omron | ||
Coil Voltage 5V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 10A | ||
Number of Poles 1 | ||
Series G5Q | ||
Coil Resistance 125 Ω | ||
Coil Power 200mW | ||
Isolation Coil To Contact 8kV | ||
Number of Coils Single | ||
- COO (Country of Origin):
- CN
The Omron miniature power relay with 1-pole and 10A switching capacity. Rated coil voltage is 5Vdc and use for output applications of control equipment.
Excellent switching performance for a variety of loads
Small, yet provides 8-kV impulse withstand voltage (between coil and contacts)
Low coil power consumption (SPST-NO: 200 mW, SPDT: 400 mW)
Coil insulation system: Class F (UL1446)
IEC/EN 60335-1 confor
Small, yet provides 8-kV impulse withstand voltage (between coil and contacts)
Low coil power consumption (SPST-NO: 200 mW, SPDT: 400 mW)
Coil insulation system: Class F (UL1446)
IEC/EN 60335-1 confor
