Omron PCB Non-Latching Relay, 24V dc Coil, 10A Switching Current, SPDT
- RS Stock No.:
- 232-6285
- Mfr. Part No.:
- G5Q-1-HA-PW DC24 (TY)
- Brand:
- Omron
Bulk discount available
Subtotal (1 tray of 500 units)*
£1,200.50
(exc. VAT)
£1,440.50
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Tray* |
|---|---|---|
| 500 - 1000 | £2.401 | £1,200.50 |
| 1500 + | £2.351 | £1,175.50 |
*price indicative
- RS Stock No.:
- 232-6285
- Mfr. Part No.:
- G5Q-1-HA-PW DC24 (TY)
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Product Type | Non-Latching Relay | |
| Coil Voltage | 24V dc | |
| Contact Configuration | SPDT | |
| Mount Type | PCB | |
| Series | G5Q | |
| Terminal Type | Solder | |
| Switching Current | 10A | |
| Switching AC Voltage | 277V ac | |
| Minimum Operating Temperature | -40°C | |
| Switching DC Voltage | 30V dc | |
| Maximum Operating Temperature | 105°C | |
| Coil Resistance | 1.4kΩ | |
| Height | 15.8mm | |
| Length | 20.3mm | |
| Width | 10.3mm | |
| Coil Power | 400mW | |
| Standards/Approvals | VDE, RoHS, IEC/EN 60335-1 | |
| Contact Material | Silver Alloy | |
| Contact Resistance | 100mΩ | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Product Type Non-Latching Relay | ||
Coil Voltage 24V dc | ||
Contact Configuration SPDT | ||
Mount Type PCB | ||
Series G5Q | ||
Terminal Type Solder | ||
Switching Current 10A | ||
Switching AC Voltage 277V ac | ||
Minimum Operating Temperature -40°C | ||
Switching DC Voltage 30V dc | ||
Maximum Operating Temperature 105°C | ||
Coil Resistance 1.4kΩ | ||
Height 15.8mm | ||
Length 20.3mm | ||
Width 10.3mm | ||
Coil Power 400mW | ||
Standards/Approvals VDE, RoHS, IEC/EN 60335-1 | ||
Contact Material Silver Alloy | ||
Contact Resistance 100mΩ | ||
The Omron miniature power relay with 1-pole and 10A switching capacity. Rated coil voltage is 24Vdc and use for output applications of control equipment.
Excellent switching performance for a variety of loads
Small, yet provides 8-kV impulse withstand voltage (between coil and contacts)
Low coil power consumption (SPST-NO: 200 mW, SPDT: 400 mW)
Coil insulation system: Class F (UL1446)
IEC/EN 60335-1 confor
