Finder Panel Modular Step Relay, 24V ac Coil, 10A Switching Current, DPST

View all Power Relays

Subtotal (1 unit)*

£16.06

(exc. VAT)

£19.27

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 106 unit(s) ready to ship
  • Plus 7 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£16.06

*price indicative

RS Stock No.:
225-4655
Mfr. Part No.:
26.04.8.024.0000
Brand:
Finder
Find similar products by selecting one or more attributes.
Select all

Brand

Finder

Coil Voltage

24V ac

Product Type

Modular Step Relay

Contact Configuration

DPST

Mount Type

Panel

Series

26

Terminal Type

Screw

Switching Current

10A

Minimum Operating Temperature

-40°C

Switching AC Voltage

400V ac

Coil Resistance

70Ω

Maximum Operating Temperature

70°C

Coil Power

4.5W

Length

58mm

Standards/Approvals

CE, EAC, RoHS

Width

17mm

Height

84mm

Contact Material

Silver Alloy

Finder 26 series Modular Step Relay, 24V AC Coil Voltage, 10A Switching Current - 26.04.8.024.0000


This modular step relay is designed for efficient control in various electrical applications. Suitable for panel mounting, it operates at a coil voltage of 24V AC and features a double pole, single throw (DPST) configuration. The relay has been built to perform reliably within a temperature range of -40°C to +40°C and supports a maximum switching voltage of 400V AC. With a robust lifespan of up to 100,000 cycles, this product meets high operational demands efficiently.

Features & Benefits


• Operates with a 24V AC coil for versatile applications

• DPST configuration allows for simultaneous switching of two circuits

• Designed for easy integration with screw terminal connections

• Capable of handling up to 10A of switching current

• Complies with CE standards for enhanced safety

• Rugged construction for a lifespan of 100,000 cycles

Applications


• Ideal for lighting control in corridors and bedrooms

• Suitable for living room light automation

• Used for automation tasks in offices and hospitals

• Useful in control that require high voltage relay functions

What type of load can this relay handle when switching?


This relay can manage a maximum switching current of 10A at 400V AC, supporting various load types including incandescent and fluorescent lamps.

How does the relay accommodate different switching sequences?


The modular step relay provides a choice of six distinct switching sequences, allowing for flexible control setups in your electrical systems.

What kind of terminal connections does this relay use?


The relay features screw terminal connections, ensuring robust and secure wiring to accommodate different installation needs.

What are the environmental operating conditions for this relay?


It can function efficiently within a temperature range of -40°C to +40°C, making it suitable for diverse working environments.
