Releco Plug In Latching Power Relay, 115V ac Coil, 5A Switching Current, DPDT
- RS Stock No.:
- 213-0816
- Mfr. Part No.:
- C9-R21 / AC 115 V
- Brand:
- Releco
Sorry, we couldn't check our stock levels right now. Please try refreshing the page.
Not available for guaranteed pre 9am/10am delivery
Added
Price Each
£38.15
(exc. VAT)
£45.78
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £38.15 |
| 5 - 9 | £37.39 |
| 10 - 14 | £36.62 |
| 15 + | £35.86 |
- RS Stock No.:
- 213-0816
- Mfr. Part No.:
- C9-R21 / AC 115 V
- Brand:
- Releco
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- ES
Product Details
5A DPCO Latching - C9 Series
Relays have a test button and mechanical flag indicator fitted as standard. The test button is colour coded and dual function, push to test or lift to latch. A removable marking label is fitted to each relay. The maximum switching voltage is 250 V ac and the operating temperature is -40 to +60°C.
Contacts remain latched on even after the supply is removed from the 'set' input
Contacts are switched off by pulsing the 'reset' input
Relay socket also available (see stock no. 437-783)
Contacts are switched off by pulsing the 'reset' input
Relay socket also available (see stock no. 437-783)
Approvals
UL; LLOYD'S; CSA; SEV; NEMKO; SETI; SEMKO; DEMKO; OVE
Specifications
Attribute | Value |
|---|---|
| Coil Voltage | 115V ac |
| Contact Configuration | DPDT |
| Mounting Type | Plug In |
| Switching Current | 5A |
| Latching | Yes |
| Terminal Type | Through Hole |
| Maximum Switching Voltage AC | 120V ac |
| Maximum Switching Voltage DC | 30V dc |
| Length | 28mm |
| Coil Resistance | 10Ω |
| Coil Power | 1.2W |
| Isolation Coil To Contact | 2kV |
| Maximum Operating Temperature | +60°C |
| Minimum Operating Temperature | -40°C |
| Contact Material | Gold Plated |
| Life | 10 Million (AC Mechanical) cycles, 20 Million (DC Mechanical) cycles |
| Height | 37.5mm |
| Depth | 21mm |
| Maximum Switching Power AC | 600 kVA |
| Application | Power |
| Dimensions | 28 x 37.5 x 21mm |
