Omron DIN Rail Power Relay, 48V ac/dc Coil, 6A Switching Current, SPDT
- RS Stock No.:
- 178-8270
- Mfr. Part No.:
- G2RV-SR500 AC/DC48
- Brand:
- Omron
Bulk discount available
Subtotal (1 unit)*
£15.93
(exc. VAT)
£19.12
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- 239 left, ready to ship
- Final 9 unit(s) shipping from 27 October 2025
Units | Per unit |
|---|---|
| 1 - 4 | £15.93 |
| 5 - 9 | £15.45 |
| 10 + | £14.81 |
*price indicative
- RS Stock No.:
- 178-8270
- Mfr. Part No.:
- G2RV-SR500 AC/DC48
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Coil Voltage | 48V ac/dc | |
| Contact Configuration | SPDT | |
| Mounting Type | DIN Rail | |
| Switching Current | 6A | |
| Number of Poles | 1 | |
| Latching | No | |
| Series | G2RV | |
| Terminal Type | Push In | |
| Maximum Switching Voltage AC | 440V ac | |
| Maximum Switching Voltage DC | 125V dc | |
| Maximum Switching Current AC | 6 A | |
| Maximum Switching Current DC | 6 A | |
| Length | 6.2mm | |
| Coil Power | 250mW | |
| Maximum Operating Temperature | +55°C | |
| Minimum Operating Temperature | -40°C | |
| Height | 90mm | |
| Depth | 77.9mm | |
| Life | 5000000 (Minimum) operations | |
| Maximum Switching Power AC | 1500 (Resistive Load) VA, 500 (Induction Load) VA | |
| Maximum Switching Power DC | 180 (Resistive Load) W, 60 (Inductive Load) W | |
| Application | Industrial | |
Select all | ||
|---|---|---|
Brand Omron | ||
Coil Voltage 48V ac/dc | ||
Contact Configuration SPDT | ||
Mounting Type DIN Rail | ||
Switching Current 6A | ||
Number of Poles 1 | ||
Latching No | ||
Series G2RV | ||
Terminal Type Push In | ||
Maximum Switching Voltage AC 440V ac | ||
Maximum Switching Voltage DC 125V dc | ||
Maximum Switching Current AC 6 A | ||
Maximum Switching Current DC 6 A | ||
Length 6.2mm | ||
Coil Power 250mW | ||
Maximum Operating Temperature +55°C | ||
Minimum Operating Temperature -40°C | ||
Height 90mm | ||
Depth 77.9mm | ||
Life 5000000 (Minimum) operations | ||
Maximum Switching Power AC 1500 (Resistive Load) VA, 500 (Induction Load) VA | ||
Maximum Switching Power DC 180 (Resistive Load) W, 60 (Inductive Load) W | ||
Application Industrial | ||
- COO (Country of Origin):
- MY
When 1788270 is no longer for sale, please see RS article 2711841 for the updated version in the new range of relays from Omron.
Having been designed from first principles, instead of being adapted from a PCB relay, Omron’s G2RV series is the only genuine slim industrial relay on the market. As a result, the G2RV offers a wide array of benefits to machine manufacturers and panel builders. Just 6mm wide, the relay is ideal for compact panels and equipment, yet it offers all of the durability and reliability required for industrial applications.
Push-in plus Technology – easy wiring
Lockable test switch models available
Large plug-in pins – excellent connection
LED/mechanical flag – check operation
Transparent housing – check condition
Slim outline – space saving
Special input type with gold plated contacts
G3RV compatible
Lockable test switch models available
Large plug-in pins – excellent connection
LED/mechanical flag – check operation
Transparent housing – check condition
Slim outline – space saving
Special input type with gold plated contacts
G3RV compatible
Note
This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.
