Hongfa Europe GMBH PCB Mount Power Relay, 5V dc Coil, 15A Switching Current, SPST
- RS Stock No.:
- 176-2643
- Mfr. Part No.:
- HF3FA/005-HTF
- Brand:
- Hongfa Europe GMBH
Subtotal (1 box of 100 units)*
£85.50
(exc. VAT)
£102.60
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 300 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 100 + | £0.855 | £85.50 |
*price indicative
- RS Stock No.:
- 176-2643
- Mfr. Part No.:
- HF3FA/005-HTF
- Brand:
- Hongfa Europe GMBH
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Hongfa Europe GMBH | |
| Coil Voltage | 5V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 15A | |
| Number of Poles | 1 | |
| Latching | No | |
| Terminal Type | PCB Pin | |
| Maximum Switching Voltage AC | 277V | |
| Maximum Switching Voltage DC | 28V dc | |
| Maximum Switching Current DC | 15 A | |
| Maximum Switching Current AC | 15 A | |
| Length | 19mm | |
| Coil Resistance | 70Ω | |
| Coil Power | 360mW | |
| Depth | 15.2mm | |
| Minimum Operating Temperature | -40°C | |
| Life | 1 x 10^7 cycles | |
| Series | HF3FA | |
| Isolation Coil To Contact | 2.5kV ac | |
| Height | 15.5mm | |
| Maximum Operating Temperature | +85°C | |
| Contact Material | Silver Alloy | |
| Maximum Switching Power AC | 2.77 kVA | |
| Maximum Switching Power DC | 280 W | |
| Select all | ||
|---|---|---|
Brand Hongfa Europe GMBH | ||
Coil Voltage 5V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 15A | ||
Number of Poles 1 | ||
Latching No | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 277V | ||
Maximum Switching Voltage DC 28V dc | ||
Maximum Switching Current DC 15 A | ||
Maximum Switching Current AC 15 A | ||
Length 19mm | ||
Coil Resistance 70Ω | ||
Coil Power 360mW | ||
Depth 15.2mm | ||
Minimum Operating Temperature -40°C | ||
Life 1 x 10^7 cycles | ||
Series HF3FA | ||
Isolation Coil To Contact 2.5kV ac | ||
Height 15.5mm | ||
Maximum Operating Temperature +85°C | ||
Contact Material Silver Alloy | ||
Maximum Switching Power AC 2.77 kVA | ||
Maximum Switching Power DC 280 W | ||
- COO (Country of Origin):
- CN
Offers excellent board space savings
Surge withstand voltage up to 1500V, meets FCC Part 68
High contact capacity 1A 30VDC
Low power consumption
Single side stable and latching type available
Single or double coil winding type available
Environmental friendly product
Outline Dimensions: (14.0 x 9.0 x 5.0) mm
Surge withstand voltage up to 1500V, meets FCC Part 68
High contact capacity 1A 30VDC
Low power consumption
Single side stable and latching type available
Single or double coil winding type available
Environmental friendly product
Outline Dimensions: (14.0 x 9.0 x 5.0) mm
