Hongfa Europe GMBH PCB Mount Power Relay, 24V dc Coil, 15A Switching Current, SPST
- RS Stock No.:
- 176-2645
- Mfr. Part No.:
- HF3FA/024-HTF
- Brand:
- Hongfa Europe GMBH
Sorry, we couldn't check our stock levels right now. Please try refreshing the page.
Not available for guaranteed pre 9am/10am delivery
Added
Price Each (In a Box of 100)
£0.791
(exc. VAT)
£0.949
(inc. VAT)
| Units | Per unit | Per Box* |
| 100 - 900 | £0.791 | £79.10 |
| 1000 - 1900 | £0.735 | £73.50 |
| 2000 - 4900 | £0.696 | £69.60 |
| 5000 + | £0.633 | £63.30 |
| *price indicative | ||
- RS Stock No.:
- 176-2645
- Mfr. Part No.:
- HF3FA/024-HTF
- Brand:
- Hongfa Europe GMBH
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Hongfa SPNO Non-Latching Relay
The Hongfa SPNO non-latching PCB mount relay has a low mounting height of 15.5mm. It is actuated with the help of a 24VDC coil. The resistive load voltage handling capacity is 15A at 277VAC. This relay is a subminiature high power relay. It has silver alloy contacts.
Features and Benefits
• High power switching up to 280W in case of DC
• Service temperature range of -40°C and 85°C
• Isolation between coil and contact is 2.5KV
• Durability up to 1 x 107 cycles
• Environmental friendly product
• Service temperature range of -40°C and 85°C
• Isolation between coil and contact is 2.5KV
• Durability up to 1 x 107 cycles
• Environmental friendly product
Applications
• Automotive engines
• Household appliances
• Industrial machinery
• Medical equipment
• Telecommunication equipment
• Household appliances
• Industrial machinery
• Medical equipment
• Telecommunication equipment
Specifications
Attribute | Value |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | SPST |
| Mounting Type | PCB Mount |
| Switching Current | 15A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | PCB Pin |
| Maximum Switching Voltage AC | 277V |
| Maximum Switching Voltage DC | 28V dc |
| Maximum Switching Current AC | 15 A |
| Maximum Switching Current DC | 15 A |
| Length | 19mm |
| Coil Resistance | 1600Ω |
| Coil Power | 360mW |
| Depth | 15.2mm |
| Height | 15.5mm |
| Series | HF3FA |
| Minimum Operating Temperature | -40°C |
| Life | 1 x 10^7 cycles |
| Contact Material | Silver Alloy |
| Maximum Operating Temperature | +85°C |
| Isolation Coil To Contact | 2.5kV ac |
| Maximum Switching Power AC | 2.77 kVA |
| Maximum Switching Power DC | 280 W |
