Panasonic PCB Mount Power Relay, 5V dc Coil, 10A Switching Current, 4PDT
- RS Stock No.:
- 173-8180
- Mfr. Part No.:
- SP4-P-DC5V
- Brand:
- Panasonic
Subtotal (1 box of 10 units)*
£276.65
(exc. VAT)
£331.98
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Box* |
|---|---|---|
| 10 + | £27.665 | £276.65 |
*price indicative
- RS Stock No.:
- 173-8180
- Mfr. Part No.:
- SP4-P-DC5V
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Coil Voltage | 5V dc | |
| Contact Configuration | 4PDT | |
| Mounting Type | PCB Mount | |
| Switching Current | 10A | |
| Number of Poles | 4 | |
| Latching | No | |
| Terminal Type | Through Hole | |
| Length | 51mm | |
| Coil Resistance | 83Ω | |
| Coil Power | 300mW | |
| Maximum Operating Temperature | +60°C | |
| Isolation Coil To Contact | 3kVrms | |
| Life | 50000000 (Electrical) cycles | |
| Minimum Operating Temperature | -50°C | |
| Height | 22mm | |
| Depth | 25.6mm | |
| Contact Material | Silver Alloy | |
| Maximum Switching Power DC | 300 W | |
| Maximum Switching Power AC | 2.5 kVA | |
| Application | Power | |
| Select all | ||
|---|---|---|
Brand Panasonic | ||
Coil Voltage 5V dc | ||
Contact Configuration 4PDT | ||
Mounting Type PCB Mount | ||
Switching Current 10A | ||
Number of Poles 4 | ||
Latching No | ||
Terminal Type Through Hole | ||
Length 51mm | ||
Coil Resistance 83Ω | ||
Coil Power 300mW | ||
Maximum Operating Temperature +60°C | ||
Isolation Coil To Contact 3kVrms | ||
Life 50000000 (Electrical) cycles | ||
Minimum Operating Temperature -50°C | ||
Height 22mm | ||
Depth 25.6mm | ||
Contact Material Silver Alloy | ||
Maximum Switching Power DC 300 W | ||
Maximum Switching Power AC 2.5 kVA | ||
Application Power | ||
- COO (Country of Origin):
- JP
