RS PRO Modified Sine Wave 2000W Power Inverter, 12V dc Input, 230V Output
- RS Stock No.:
- 179-3324
- Brand:
- RS PRO
19 In stock - FREE next working day delivery available
1 available from Europe for delivery within 1 working day(s).
Added
Price Each
£294.88
(exc. VAT)
£353.86
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £294.88 |
| 5 - 9 | £286.04 |
| 10 - 24 | £277.19 |
| 25 - 49 | £268.34 |
| 50 + | £259.50 |
- RS Stock No.:
- 179-3324
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
RS PRO 2000 W Fixed Installation DC-AC Power Inverter, 12 V DC/230 V AC
Need to run multiple electrical devices but not near an AC power source? Then this DC-AC power inverter from the RS PRO range is the ideal solution. It takes a DC source, such as a car battery, and transforms it to 230 V AC output, making it compatible with any device you would run from your home.
This power inverter has been built with safety in mind. It offers protection from overloading, overheating, reverse polarity and short circuits. Its aluminium casing ensures that heat is dispersed safely and LED indicators on the front panel show that it's working correctly. There's also a low-voltage alarm and automatic shutoff, giving you peace of mind that your devices are running safely.
This power inverter has been built with safety in mind. It offers protection from overloading, overheating, reverse polarity and short circuits. Its aluminium casing ensures that heat is dispersed safely and LED indicators on the front panel show that it's working correctly. There's also a low-voltage alarm and automatic shutoff, giving you peace of mind that your devices are running safely.
Features and Benefits
• Two universal output connections
• Maximum input current of 333.3 A
• Output current of 17.39 A
• Output frequency range of 50 Hz
• Intermittent output power of 2100 W
• Modified sine wave output waveform
• Single-phase electrical output
• Efficiency rating of > 88%
• Maximum input current of 333.3 A
• Output current of 17.39 A
• Output frequency range of 50 Hz
• Intermittent output power of 2100 W
• Modified sine wave output waveform
• Single-phase electrical output
• Efficiency rating of > 88%
• Mean Time Between Failure of 50000 hours
• Operating temperature range of -20°C to +50°C
• Chassis mounting
• Dimensions of 345 mm x 230 mm x 107.7 mm
• Weight of 4.9 kg
• Operating temperature range of -20°C to +50°C
• Chassis mounting
• Dimensions of 345 mm x 230 mm x 107.7 mm
• Weight of 4.9 kg
Specifications
Attribute | Value |
|---|---|
| Input Voltage | 12V dc |
| Output Voltage | 230V |
| Output Power Continuous | 2000W |
| Output Power Intermittent | 2100W |
| Output Power Waveform | Modified Sine Wave |
| Output Connection Type | Universal |
| Efficiency | >88% |
| MTBF | 50000h |
| Output Current | 17.39A |
| Length | 345mm |
| Width | 230mm |
| Depth | 107.7mm |
| Weight | 4.9kg |
| Minimum Temperature | -20°C |
| Special Features | Auto Reset After Being in Protected, Compact, IP22, Lightweight, Two LED indicators |
| Inverter Directionality | DC to AC |
| Mounting Type | Chassis Mount |
| Maximum Input Current | 333.3A |
| Number of Output Connections | 2 |
| Protection Features | Low-Voltage Alarm & Shutdown, Over Temperature Protection, Over Voltage Protection, Overload Protection, Reverse Polarity Protection, Short Circuit Protection |
| Maximum Temperature | +50°C |
| Standards Met | CE, ECE R10.05:2014, ECE R10.05:2014EN 61000-6-3, EN 60950-1, EN 61000-6-1, EN 61000-6-3 |
| Output Electrical Phase | 1 |
| Output Frequency Range | 50Hz |
