RS PRO Modified Sine Wave 2000W Power Inverter, 12V dc Input, 230V Output
- RS Stock No.:
- 179-3324
- Brand:
- RS PRO
Subtotal (1 unit)*
£303.73
(exc. VAT)
£364.48
(inc. VAT)
FREE delivery for orders over £50.00
- 12 unit(s) ready to ship
- Plus 3 unit(s) shipping from 17 November 2025
- Plus 9 unit(s) shipping from 03 April 2026
Units | Per unit |
---|---|
1 - 4 | £303.73 |
5 - 9 | £294.62 |
10 - 24 | £285.51 |
25 - 49 | £276.39 |
50 + | £267.29 |
*price indicative
- RS Stock No.:
- 179-3324
- Brand:
- RS PRO
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Input Voltage | 12V dc | |
Output Voltage | 230V | |
Output Power Continuous | 2000W | |
Output Power Intermittent | 2100W | |
Output Power Waveform | Modified Sine Wave | |
Output Connection Type | Universal | |
Efficiency | >88% | |
MTBF | 50000h | |
Output Current | 17.39A | |
Length | 345mm | |
Width | 230mm | |
Depth | 107.7mm | |
Weight | 4.9kg | |
Minimum Temperature | -20°C | |
Maximum Input Current | 333.3A | |
Number of Output Connections | 2 | |
Protection Features | Low-Voltage Alarm & Shutdown, Over Temperature Protection, Over Voltage Protection, Overload Protection, Reverse Polarity Protection, Short Circuit Protection | |
Mounting Type | Chassis Mount | |
Output Electrical Phase | 1 | |
Standards Met | CE, ECE R10.05:2014, ECE R10.05:2014EN 61000-6-3, EN 60950-1, EN 61000-6-1, EN 61000-6-3 | |
Maximum Temperature | +50°C | |
Special Features | Auto Reset After Being in Protected, Compact, IP22, Lightweight, Two LED indicators | |
Output Frequency Range | 50Hz | |
Inverter Directionality | DC to AC | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Input Voltage 12V dc | ||
Output Voltage 230V | ||
Output Power Continuous 2000W | ||
Output Power Intermittent 2100W | ||
Output Power Waveform Modified Sine Wave | ||
Output Connection Type Universal | ||
Efficiency >88% | ||
MTBF 50000h | ||
Output Current 17.39A | ||
Length 345mm | ||
Width 230mm | ||
Depth 107.7mm | ||
Weight 4.9kg | ||
Minimum Temperature -20°C | ||
Maximum Input Current 333.3A | ||
Number of Output Connections 2 | ||
Protection Features Low-Voltage Alarm & Shutdown, Over Temperature Protection, Over Voltage Protection, Overload Protection, Reverse Polarity Protection, Short Circuit Protection | ||
Mounting Type Chassis Mount | ||
Output Electrical Phase 1 | ||
Standards Met CE, ECE R10.05:2014, ECE R10.05:2014EN 61000-6-3, EN 60950-1, EN 61000-6-1, EN 61000-6-3 | ||
Maximum Temperature +50°C | ||
Special Features Auto Reset After Being in Protected, Compact, IP22, Lightweight, Two LED indicators | ||
Output Frequency Range 50Hz | ||
Inverter Directionality DC to AC | ||
- COO (Country of Origin):
- CN
RS PRO 2000 W Fixed Installation DC-AC Power Inverter, 12 V DC/230 V AC
This power inverter has been built with safety in mind. It offers protection from overloading, overheating, reverse polarity and short circuits. Its aluminium casing ensures that heat is dispersed safely and LED indicators on the front panel show that it's working correctly. There's also a low-voltage alarm and automatic shutoff, giving you peace of mind that your devices are running safely.
Features and Benefits
• Maximum input current of 333.3 A
• Output current of 17.39 A
• Output frequency range of 50 Hz
• Intermittent output power of 2100 W
• Modified sine wave output waveform
• Single-phase electrical output
• Efficiency rating of > 88%
• Operating temperature range of -20°C to +50°C
• Chassis mounting
• Dimensions of 345 mm x 230 mm x 107.7 mm
• Weight of 4.9 kg
