MG Chemicals 9510-300ML Black Epoxy Epoxy Resin Adhesive 300 ml
- RS Stock No.:
- 192-7570
- Mfr. Part No.:
- 9510-300ML
- Brand:
- MG Chemicals
Subtotal (1 unit)*
£69.26
(exc. VAT)
£83.11
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 29 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £69.26 |
*price indicative
- RS Stock No.:
- 192-7570
- Mfr. Part No.:
- 9510-300ML
- Brand:
- MG Chemicals
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | MG Chemicals | |
Product Material | Epoxy | |
Package Type | Cartridge | |
Package Size | 300 ml | |
Cure Time | 1 h @ 90 °C, 3 h @ 80 °C, 30 min @ 120 °C | |
Hardness | 84 Shore D | |
Thermal Conductivity | 0.3W/mK | |
Colour | Black | |
Maximum Operating Temperature | +150°C | |
Minimum Operating Temperature | -65°C | |
Operating Temperature Range | -65 → +150 °C | |
Dielectric Strength | 15.8kV/mm | |
Viscosity Description | Low | |
Physical Form | Liquid | |
Select all | ||
---|---|---|
Brand MG Chemicals | ||
Product Material Epoxy | ||
Package Type Cartridge | ||
Package Size 300 ml | ||
Cure Time 1 h @ 90 °C, 3 h @ 80 °C, 30 min @ 120 °C | ||
Hardness 84 Shore D | ||
Thermal Conductivity 0.3W/mK | ||
Colour Black | ||
Maximum Operating Temperature +150°C | ||
Minimum Operating Temperature -65°C | ||
Operating Temperature Range -65 → +150 °C | ||
Dielectric Strength 15.8kV/mm | ||
Viscosity Description Low | ||
Physical Form Liquid | ||
- COO (Country of Origin):
- CA
9510 is a black, rigid, one-part epoxy potting compound. It has unlimited working time at room temperature and does not require frozen storage. It provides excellent electrical insulation and protects against static discharges, vibration, thermal shock, environmental humidity, salt water, fungus, and many harsh chemicals. 9510 has a low viscosity and can be readily used in manual, pneumatic and robotic dispensing processes.
Up to 12 months shelf life at room temperature
Minimum cure temperature of 80 °C [176 °F]
Ready to dispense no mixing is required
Broad service temperature -65 to 150 °C [-85 to 302 °F]
Extremely high tensile and compressive strength
Minimum cure temperature of 80 °C [176 °F]
Ready to dispense no mixing is required
Broad service temperature -65 to 150 °C [-85 to 302 °F]
Extremely high tensile and compressive strength
