Panasonic 56μF Surface Mount Polymer Capacitor, 63V dc

RS Stock No.:: 758-1118
Mfr. Part No.:: EEHZC1J560P
Brand:: Panasonic

Panasonic 56μF Surface Mount Polymer Capacitor, 63V dc

Subtotal (1 unit)*

£0.94

(exc. VAT)

£1.13

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

776 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£0.94

*price indicative

RS Stock No.:: 758-1118
Mfr. Part No.:: EEHZC1J560P
Brand:: Panasonic

Panasonic Series ZC Polymer Capacitor, 56μF Capacitance, 63V DC Voltage - EEHZC1J560P

This polymer capacitor is a surface mount device designed for high-performance applications. With a capacitance of 56 μF and a voltage rating of 63V DC, it is engineered for robust functionality in demanding environments. Measuring 10 x 10.2mm, this capacitor is polarised and operates efficiently across a broad temperature range from -55 °C to +125 °C.

Features & Benefits

• Hybrid technology enhances efficiency in electronic circuits
• Low equivalent series resistance of 30 mΩ for better performance
• High temperature tolerance ensures reliability in critical applications
• AEC-Q200 compliant for use in automotive environments
• Displacement factor of 8 % allows for reduced power loss
• Extended lifespan options of 1000 hours or 4000 hours under various conditions

Applications

• Used with automotive electronic systems requiring high reliability
• Suitable for power supply circuits in industrial automation
• Ideal for audio and signal needing low ESR
• Employed in equipment operating in extreme temperature conditions

What advantages does the low equivalent series resistance offer in practical scenarios?

The low equivalent series resistance allows for improved energy efficiency and less heat generation, which is crucial for maintaining optimal performance in high-frequency applications. This results in better signal integrity and overall stability in electronic designs.

How does the operating temperature range affect its performance?

The extensive temperature range of -55 °C to +125 °C allows it to function reliably in diverse environmental conditions, making it suitable for both automotive and industrial applications where temperature fluctuations can occur.

What are the main considerations for mounting this component on a PCB?

Surface mount capacitors should be placed on flat, clean surfaces with adequate soldering techniques to ensure optimal electrical and thermal performance. It's also essential to consider the spacing around the component to accommodate thermal expansion during operation.

What is the significance of AEC-Q200 compliance for this product?

AEC-Q200 compliance signifies that the product meets stringent automotive standards, ensuring reliability and performance in vehicles. This is essential for devices used in automotive applications where failure could lead to significant safety concerns.

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Panasonic
	Technology	Hybrid
	Capacitance	56µF
	Voltage	63V dc
	Mounting Type	Surface Mount
	Equivalent Series Resistance	30mΩ
	Lead Pitch	4.6mm
	Tolerance	±20%
	Length	10.2mm
	Height	12mm
	Maximum Operating Temperature	+125°C
	Dimensions	10 x 10.2mm
	Series	ZC
	Automotive Standard	AEC-Q200
	Lifetime	1000 h, 4000h
	Dissipation Factor	8%
	Polarised	Polar
	Leakage Current	35.2 μA
	Ripple Current	1400mArms
	Minimum Operating Temperature	-55°C
	Diameter	10mm

	Select all
	Brand Panasonic
	Technology Hybrid
	Capacitance 56µF
	Voltage 63V dc
	Mounting Type Surface Mount
	Equivalent Series Resistance 30mΩ
	Lead Pitch 4.6mm
	Tolerance ±20%
	Length 10.2mm
	Height 12mm
	Maximum Operating Temperature +125°C
	Dimensions 10 x 10.2mm
	Series ZC
	Automotive Standard AEC-Q200
	Lifetime 1000 h, 4000h
	Dissipation Factor 8%
	Polarised Polar
	Leakage Current 35.2 μA
	Ripple Current 1400mArms
	Minimum Operating Temperature -55°C
	Diameter 10mm
